Multi ( Extraction ) Mantles : 3 Recess Model
The 3 place multi position ( extraction ) mantle has a built-in electronic controller and offers a choice of heater only ( EME3 ) or heater/stirrer ( EMEA3 ) combination.
The vented case's unique air flow ensures the outer case remains safe to touch.
For both Heater EME3 and Heater/Stirrer EMEA3 models
Individual built-in solid state electronic controls enable easy regulation of heater, while removing sparking associated with mechanical switching
Three 12.7 mm diameter support rods are included
Round bottom flask capacity from 100 ml to 1000 ml at all 3 positions
Top cover is polypropylene and external surfaces are powder coated giving good general chemical resistance
Coiled heating element is suspended within a thermal insulating cartridge to provide maximum heat transfer and support
Earth ( ground ) screen encloses the heater for added safety
Individual heater cartridges are replaceable
Neon lights indicate when power is on and supplied to heaters and, if applicable, supplied to stirrers
Additional Features for Heater/Stirrer EMEA3 models only
Allow the solution to be stirred and heated simultaneously
Provide stirring speeds of between 50 to 1000 rpm
One stirring control operates each set of three recesses
Technical Specification
Material	Polypropylene top on powder-coated aluminium
Max element temp.	450°C
Heater Model Ordering Information
Model	Flask	Dimensions	Reces	Electrical	Shipping
	Capacity	D x W x H. mm		Requirements	Weight, kg
EME30100/CEB	3 x 100 ml	270 x 640 x 110	3	230v 50/ 60Hz, 180W UK and EU plug	6.2
EME30100/CEBX1	3 x 100 ml	270 x 640 x 110	3	115v 50/ 60Hz, 180W	6.2
EME30250/CEB	3 x 250 ml	270 x 640 x 110	3	230v 50/ 60Hz, 450W UK and EU plug	6.2
EME30250/CEBX1	3 x 250 ml	270 x 640 x 110	3	115v 50/ 60Hz/ 450W	6.2
EME30500/CEB	3 x 500 ml	285 x 755 x 130	3	230v 50/ 60Hz, 600W UK and EU plug	7.4
EME30500/CEBX1	3 x 500 ml	285 x 755 x 130	3	115v 50/ 60Hz, 600W	7.4
EME31000/CEB	3 x 1000 ml	285 x 755 x 130	3	230v 50/ 60Hz, 900W UK and EU plug	7.4
EME31000/CEBX1	3 x 1000 ml	285 x 755 x 130	3	115v 50/ 60Hz, 900W	7.4
Heating/Stirrer Model Ordering Information
Model	Flask	Dimensions	Reces	Electrical	Shipping
	Capacity	D x W x H. mm		Requirements	Weight, kg
EMEA30100/CE	3 x 100 ml	270 x 640 x 110	3	230v 50/ 60Hz, 220W UK and EU plug	7
EMEA30100/CEX1	3 x 100 ml	270 x 640 x 110	3	115v 50/ 60Hz, 220W	7
EMEA30250/CE	3 x 250 ml	270 x 640 x 110	3	230v 50/ 60Hz, 490W UK and EU plug	7
EMEA30250/CEX1	3 x 250 ml	270 x 640 x 110	3	115v 50/ 60Hz, 490W	7
EMEA30500/CE	3 x 500 ml	285 x 755 x 130	3	230v 50/ 60Hz, 640W UK and EU plug	8.4
EMEA30500/CEX1	3 x 500 ml	285 x 755 x 130	3	115v 50/ 60Hz, 640W	8.4
EMEA31000/CE	3 x 1000 ml	285 x 755 x 130	3	230v 50/ 60Hz, 940W UK & EU plug	8.4
EMEA31000/CEX1	3 x 1000 ml	285 x 755 x 130	3	115v 50/ 60Hz, 940W	8.4
