Digital Refractometer for Seawater Analysis HI-96822 Hanna Instruments

Specifications

Salinity Content Range

0 to 50 PSU; 0 to 150 ppt; 1.000 to 1.114 Specific Gravity ( 20/20 )

Salinity Content Resolution

1 PSU; 1 ppt; 0.001 Specific Gravity ( 20/20 )

Salinity Content Accuracy ( @20 ºC/68 ºF )

±2 PSU; ±2 ppt; ±0.002 Specific Gravity ( 20/20 )

Temperature Range

0 to 80 °C ( 32 to 176 °F )

Temperature Resolution

0.1 °C ( 0.1 °F )

Temperature Accuracy

±0.3 °C ( ±0.5 °F )

Temperature Compensation

Automatic between 0 and 40 °C ( 32 to 104 °F )

Measurement Time

Approximately 1.5 seconds

Minimum Sample Volume

100 μL ( to cover prism totally )

Light Source

Yellow LED

Sample Cell

Stainless steel ring and flint glass prism

Auto-off

After three minutes of inactivity

Enclosure Rating

IP 65

Battery Type / Life

9 V / Approximately 5000 readings

Dimensions / Weight

192 x 102 x 67 mm ( 7.6 x 4.01 x 2.6” ) / 420 g ( 14.8 oz.)

Ordering Information

HI96822 is supplied with battery and instruction manual

Warranty

1 year
