Corning Hotplate PC-400D & PC-600D

Description

Microprocessor maintains consistent and repeatable temp. settings from 5 °C ( if ambient temp. is 0 °C or lower ) up to 550 °C

Digital LED temperature display is adjustable in 5 °C increments and blinks until set temperature is reached

Bright LED HOT TOP icon lights up when top plate is over 60 °C, even when heat control is turned off

Two piece casting design deflects spills away from electronics and includes a built in mount for an optional 18 in. ( 45.7 cm ) support rod ( Cat. No. 440129 )

Certifications

CE marked and UL/cUL approved

Specifications

Dimensions ( L x W x H )

15.37 x 11 x 4.62 in. ( 39.03 x 27.94 x 11.73 cm )

Height ( Metric )

11.73 cm

Length ( Metric )

39.03 cm

Wattage

1043 W

Width ( Metric )

27.94 cm

Weight ( English )

9.92 lb.

Height ( English )

4.62 in.

Length ( English )

15.37 in.

Temperature Range ( Metric )

5° to 550 °C

Width ( English )

11 in.

Warranty

2 Years

Weight ( Metric )

4.5 kg

Model

PC-400D

PC-600D

Temp. range

Ambient +5 - 550 °C

Temp. accuracy

±2 °C

Material, top

Pyroceram

Top plate size

12.7 x 17.8 cm

25.4 x 25.4 cm

Dimensions

10.8 x 19.7 x 28 cm

11.75 x 19.7 x 39.1 cm

Display

Digital

Power Supply

230 V/50 Hz
