Hotplate stirrers digital CD162 & SD162 Stuart

Specifications

Model

CD162

SD162

Plate material

Glass ceramic

Aluminium silicon alloy

Plate dimensions, mm

160 x 160

160 x 160

Heated area, mm

120 x 120

160 x 160

Heater power, W

500

700

Display resolution °C

1

1

Max. plate temp. °C with probe °C

450

300

Stirrer speed

200

200

Control accuracy with probe °C

±0.5°C

±0.5°C

Stirrer speed, rpm

200 to 1300

200 to 1300

Max. stirring capacity, litres

15

15

Net weight, kg

3.4

3.4

Overall dimensions ( w x d x h )

190 x 300 x 110

190 x 300 x 110

Electrical supply

230 V, 50 Hz

230 V, 50 Hz

Model

Description

CD162

Digital stirrer/hotplate, ceramic plate, 500 W

SD162

Digital stirrer/hotplate, aluminium plate, 700 W

CD162/1

Temperature probe, stainless steel

SR1

Retort rod, 600 x 12 mm
