Incubator BD & BF Binder

Specifications

Model BF 56

Model BF 115

Model BF 260

Description

BF056 – 230 V

Description

BF115 - 230V

Description

BF260 – 230 V

Article Number

9010-0313

Article Number

9010-0315

Article Number

9010-0319

Performance Data Temperature

Temp. range 7 °C above ambient temp. to [ °C ]

100

Temp. range 8 °C above ambient temp. to [ °C ]

100

Temp. range 7 °C above ambient temp. to [ °C ]

100

Temp. variation at 37 °C [ ± K ]

0,3

Temp. variation at 37 °C [± K]

0,3

Temp. variation at 37 °C [± K]

0,3

Temp. fluctuation at 37 °C [ ± K ]

0,1

Temp. fluctuation at 37 °C [± K]

0,1

Temp. fluctuation at 37 °C [± K]

0,1

Heating-up time to 37 °C [ min ]

8

Heating-up time to 37 °C [ min ]

8

Heating-up time to 37 °C [ min ]

12

Recovery time after 30 seconds door open at 37 °C [ min ]

5

Recovery time after 30 seconds door open at 37 °C [ min ]

4

Recovery time after 30 seconds door open at 37 °C [ min ]

5

Electrical data

Rated Voltage [ V ]

230

Rated Voltage [ V ]

230

Rated Voltage [ V ]

230

Power frequency [ Hz ]

50/60

Power frequency [ Hz ]

50/60

Power frequency [ Hz ]

50/60

Nominal power [ kW ]

0,4

Nominal power [ kW ]

0,4

Nominal power [ kW ]

0,9

Unit fuse [ A ]

6,3

Unit fuse [ A ]

6,3

Unit fuse [ A ]

8

Phase ( Nominal voltage )

1~

Phase ( Nominal voltage )

1~

Phase ( Nominal voltage )

1~

Measures - Outer dimensions

Width net [ mm ]

560

Width net [ mm ]

710

Width net [ mm ]

810

Height net [ mm ]

625

Height net [ mm ]

735

Height net [ mm ]

965

Depth net [ mm ]

565

Depth net [ mm ]

605

Depth net [ mm ]

760

Wall clearance back [ mm ]

160

Wall clearance back [ mm ]

160

Wall clearance back [ mm ]

160

Wall clearance sidewise [ mm ]

100

Wall clearance sidewise [ mm ]

100

Wall clearance sidewise [ mm ]

100

Measures - Doors

Unit doors

1

Unit doors

1

Unit doors

1

Measures - Internal Dimensions

Width [ mm ]

400

Width [ mm ]

550

Width [ mm ]

650

Height [ mm ]

440

Height [ mm ]

550

Height [ mm ]

780

Depth [ mm ]

340

Depth [ mm ]

380

Depth [ mm ]

510

Measures

Interior volume [ L ]

59

Interior volume [ L ]

114

Interior volume [ L ]

257

Net weight of the unit ( empty ) [ kg ]

38

Net weight of the unit ( empty ) [ kg ]

54

Net weight of the unit ( empty ) [ kg ]

85

permitted load [ kg ]

-

permitted load [ kg ]

150

-

Load per rack [ kg ]

15

Load per rack [ kg ]

30

Load per rack [ kg ]

30

Environment-specific data

Energy consumption at 37 °C

60 Wh/h

Energy consumption at 37 °C

60 Wh/h

Energy consumption at 37 °C

70 Wh/h

Sound-pressure level [ dB ( A )]

-

Sound-pressure level [ dB ( A )]

43

-

Fixtures

Number of shelves

( standard/maximum )

2/4

Number of shelves

( standard/maximum )

2/5

Number of shelves

( standard/maximum )

2/8
