| Specification |
| Product Lab Incubator |
| Model IN-010 |
| Capacity 16, 40, 57, 75, 90, 110, 150, 200 L |
| Control system Microprocessor system |
| Temp control PID |
| Temp setting Digital |
| Temp readout Digital |
| Air convection Forced convection by fan |
| Temp uniformity ±3.0 ºC at 37 ºC |
| Temp stability ±0.5 ºC at 37 ºC |
| Over-temp alarm & shutout Yes, 4 ºC to the set point |
| Timer Digital, 99 hr. 59 min. + HOLD |
| Temperature range Ambient + 5 ºC to 75 ºC |
| Standard accessory 2 S/S mesh shelves, adjustable |
| Key Features : |
| 1 Temperature uniformity & Stability are approximated which may be varied under the different operation environment. |
| 2 The above specifications are subject to change without advanced notice. |
| - Intended use: For microbiological studies for tissue culture and viruses incubation. |
| - A viewfinder (window) made by temper glass mounted on front door easy for monitoring specimens, which ensures to prevent from the possible broken glass door and also do not require to open door for monitoring samples. |
| - Features a double-walled chamber insulated by glass fiber for durability and good heat retention. (Rock wool can create respiratory disease and cancer.) |
| - Timer is working only when the set temperature has been stabilized. Functions audible & visible alarm against the over heating. |
| - Adjustable fresh air inlet port at bottom and top provides control of the amount of convective air. |
| - Built-in module temperature controller provides an accurate temperature display |
| - Safety devices: |
| - Over temperature alarm and shutout to 4ºC above set point. |
| - Independent safety switch protects specimen from excessive heating at 80ºC if the primary control fails. |
| - Optional leakage breaker with O.C. |
| - Audible & visible alarm indicated by lamp |
| - Timer is displayed by “END” when the incubation cycle is completed. When alarm is working. |
| - Memory stores the temperature and the past time if door is opened during operation |
| Specification |
| Product Lab Incubator |
| Model IN-601 & IN-601 ( Digital ) |
| Capacity 34, 53, 75, 90, 110, 150 L |
| Control system Analog Microprocessor |
| Temp control ON / OFF PID |
| Temp setting Analog Digital |
| Temp readout Thermometer Digital |
| Air convection Natural ( Gravity ) Forced convection |
| Temp uniformity ±5.0ºC at 37ºC ±3.0ºC at 37ºC |
| Temp stability ±3.0 ºC at 37 ºC ±1.0 ºC at 37 ºC |
| Over-temp alarm & shutout At 80 ºC 4 ºC to the set point |
| Timer Mechanical, 180 min + HOLD |
| Temperature range Ambient + 5 ºC to 75 ºC |
| Standard accessory 2 S/S mesh shelves, adjustable |
| Key Features |
| IN-601 ( Digital ) |
| - Timer is working only when the set temperature has been stabilized. Functions audible & visible alarm against the over heating. |
| - Adjustable fresh air inlet port at bottom and top provides control of the amount of convective air. |
| - Built-in module temperature controller provides an accurate temperature display |
| - Safety devices: |
| - Over temperature alarm and shutout to 4 ºC above set point. |
| - Independent safety switch protects specimen from excessive heating at 80 ºC if the primary control fails. |
| - Optional leakage breaker with O.C. |
| - Audible & visible alarm indicated by lamp |
| - Timer is displayed by “END” when the incubation cycle is completed. When alarm is working. |
| - Memory stores the temperature and the past time if door is opened during operation |
| IN-601 |
| - This model is used when the samples can’t be disturbed by air current and also for use when the accurate temperature and uniformity are not critical important to users. |
| - A mercury thermometer is mounted on top of the equipment providing temperature direct reading. |
| - Comes with hydraulic thermostat sensor. |
| - The door lock is newly designed easy to lock and open. |
| - The formed door gasket is efficient to prevent the heat loss |
