Specification
| Model | SH-CH-54G | SH-CH-100G | SH-CH-149G | SH-CH-250G |
| Air Circulation | Forced | Forced | Forced | Forced |
| Temp Range | Ambient +5 °C to 70 °C ( Ambient + 9 °F to 158 °F ) | |||
| Temp Control | Microprocess Digital P I D Membrane touch controller | |||
| Time Range | 00.00 to 99 HR 59MIN ( MIN SEC ) Selectable Digital Counter Timer | |||
| Temp Accuracy & Stability | ±0.1 ℃ | |||
| Temp Uniformity | ±0.5 ℃ | |||
| Capacity | 54 L | 100 L | 150 L | 250 L |
| Demension Internal,mm | 380 × 340 × 420 | 480 x 400 x 530 | 555 x 450 x 600 | 700 × 450 × 800 |
| ( W x D x H ) inch | 14.96 x 13.39 x 16.54 | 18.90 x15.75 x 20.87 | 21.85 x 17.72 x 23.62 | 27.56 x 17.72 x 31.50 |
| Demension External,mm | 525 x 520 x 757 | 625 x 580 x 870 | 700 x 630 x 937 | 845 x 630 x 1170 |
| ( W x D x H ) inch | 20.67 x 20.47 x 29.80 | 24.61 x 22.83 x 34.25 | 27.56 x 24.80 x 37.00 | 33.27 x 24.80 x 46.06 |
| Net Weight | 40 Kg | 51 Kg | 60 Kg | 85 Kg |
| Material Internal | Stainless Steel | |||
| Material External | Steel Plate with Powder Heating Coated | |||
| Shelves | 2 Supplied ( 12 Max ) | 2 Supplied ( 15 Max ) | 2 Supplied ( 17 Max ) | 2 Supplied ( 24 Max ) |
| Heater | 400 W | 600 W | 800 W | 1000 W |
| Electrical 230 V,50/60 Hz, 1Φ | 1.7 A | 2.6 A | 3.5 A | 4.3 ( 8.3 ) A |
