Infrared Moisture Analyzer FD-660 Kett

Specifications

FD-660

Measurement

Detection of weight loss by heating & drying method

Sample weight

1 - 80 g ( optional weight sampling format )

Resoluion

The indication of 0.01 % is not guaranteed for accuracy. Weight : 0.005 g

Moisture content/Solid content : 0.1 % or 0.01 % ( selectable )

Measurement units

Moisture content ( wet base & dry base ), solid content

Measurable range

0 - 100 % ( wet base, solid content )

0 - 500 % ( dry base )

Repeatability (Standard deviation)

Samples with a weight of 5 g or  more, 0.1 % ( When using standard samples and measuring conditions as determined by Kett Electric Laboratory )

Measurement mode

Automatic halting mode

Timed halting mode ( 1 to 120 min.)

Drying Temp. range

30 - 180 ˚C ( in steps of 1 °C )

Display

Backlit LCD display ( 96 x 40 mm )

External output

RS-232C interface

Communication function

Data output from "the data logger software

FDL-02" ( option )

Storage of measurement conditions

5 types

Temp./Humidity operating range

5 - 40 °C, 85 % RH or less ( no condensation )

Heat source

Organic carbon heater ( 280 W x 2 )

Temp. sensor

Thermistor

Power supply

100 - 120 V AC / 220 - 240V AC ( 50/60 Hz )

Power consumption

Max. 900 W

External Dimensions & Weight

222 ( W ) x 360 ( D ) x 196 ( H ) mm, 3.2 kg

Sample dish

Stainless steel ( 110 mm in diameter, 11 mm in depth )

Accessories

2 sample dishes, sample dish handler, wind shield, sample dish stand, spoon, 2 spare fuses, aluminium sheet set ( 10 sheets ), power cord ( with 3P-2P plug adapter ), operating manual

Option

Printer set ( includes a printer "VZ-330", a printer interface cable "VZC-14", printer paper, and an AC adapter ), printer paper (10 rolls), package of aluminium foil sheets (500 sheets) , RS-232C cable "VZC-52", data logger software "FDL-02", sample crusher "TQ-100", deodorizing windshield case "FW-100"
