Integrity 10 Reaction Station
The Integrity 10 Reaction Station enables you to conduct 10 different reactions simultaneously within the same reaction unit, each reaction being conducted within its own cell, at its own individual temperature and stir rate.
The Integrity 10 Reaction Station is an excellent screening tool that can be used in most laboratories. It features :
10 individual, independently controllable cells
Temperature range of -30 °C to 150 °C
Stirring rate of 350 rpm - 1200 rpm
For sample volumes of 1 ml - 25 ml
Optional attachments for refluxing, and working under inert conditions
Optional multi-infrared probes for solubility/crystallisation studies
Local control via colour touchscreen
If desired, fast heating and cooling rates can be selected, with temperature ramps of between 0.1°C/min to 5°C/min. There is also a crash function for even faster temperature changes, which is ideal for kinetic determinations.
Extreme temperature accuracy is guaranteed, with a temperature stability of ± 0.2 °C and a maximum set point overshoot of 0.1 °C. The temperature may be maintained either through the block itself or by using a probe within each cell's solution.
This accuracy can be maintained over a wide temperature range of -30 °C to 150 °C, with precise, independently controlled temperature profiles, and homogeneous sample mixing may be assured with stirring rates of between 350 rpm to 1200 rpm using powerful magnetic stirrers.
The Integrity 10 is an excellent tool for establishing ideal process conditions.
IR/NIR probe ( part no. ATS10394/1 ) custom made for Integrity 10 by Hellma.
Visit the Amigo Chem web site for more information on how the Integrity10 can be incorporated onto a robotics platform
Technical Specification
Number of Positions	10
Cell Cavity Diameter	25.5 mm
Sample Volume	1 - 25 ml
Temperature Range	- 30 °C to + 150 °C
Possible temp difference	180 °C
Temperature Overshoot	0.1 °C ( maximum )
Max controlled heating cooling ramp rate	0.1 °C to 5 °C min in 0.1°C min steps
Stir Speed Range	350 - 1200 rpm
Viscosity Capacity	Glycerine at 25 °C
Recommended Stir Bars	12 x 4.5 mm ( cylindrical ) or 10 x 6 mm ( oval )
Ordering Information
Part Number	Description
PS20000	Integrity 10 with 10 individually controlled cells, UK , US & EU power leads
ATS20100	Integrity 10 reflux/inerting unit
ATS20002	SVL 22 thread inerting caps for use with ATS20100
ATS10075	Glass tubes 24 / 150 mm, SVL 22 thread pack of 10
ATS20003	Kimble thread inerting caps for use with ATS20100
ATS20004	Kimble thread 24 / 150 mm glass tubes compatible with ATS20003
ATS10055	Small volume test tubes 24 - 16 mm taper ( 3 ml ) x10
ATS10056	Reducing sleeves for ATS10055 x10
ATS10209	Small volume test tubes 24 - 11 mm taper ( 1 ml ) x 10
ATS10101	Reducing sleeves for ATS10209
AZS4206	Stirrer bars 10 / 6mm, pack of 10
AZS4235	Stirrer bars 12 / 4.5mm, pack of 10
ATS10001	Multi-Temp 10 plug-in box
ATS10027	Temperature probe, pack of 6
ATS10027 / 10	Temperature probe, pack of 10
ATS11005	Integrity software
ATS10360 / 1	Non Intrusive IR sensor, pack of 1
ATS10230	Small Intrusive IR probe in stainless steel PID-NIR5-BNSD, pack of 1
ATS10394 / 1	Large Intrusive IR and NIR probe pack of 1
