SYD-265D-1 Kinematic Viscometer |
|||
|
Spec |
|||
|
Power supply |
AC220 ± 10 %,50 Hz |
||
|
Heating power |
1000 W ( Auxiliary Heating ),600 W ( Heating ) |
||
|
Stirring motor |
6W,1200 RPM |
||
|
Temp. range |
Ambient to 100.0 ºC. |
||
|
Temp. control accuracy |
±0.0 ºC. |
||
|
Timer |
0.0 s ~ 999.9 s |
||
|
Constant temp. bath |
20 L, double shall structure |
||
|
Ambient temp. |
-10 ºC~+35 ºC |
||
|
RH |
<85 % |
||
|
Max. power consumption |
1800 W |
||
|
Capillary viscometer tubes ( Pinkevitch Viscometer ) |
7 Pcs in total. |
||
|
The inner diam. for each |
0.6,0.8,1.0, 1.2,1.5,2.0 & 2.5 mm |
||
|
Dimenssions |
530 × 400 × 670 mm |
||
|
Net Weight. |
42 Kg |
||
|
Accessories & documents List |
|||
|
Name |
Unit |
Qty |
Memo |
|
SYD-265D-1 |
Set |
1 |
|
|
( With glass inner and external cylinder,tirring device,rubber ring etc ) |
|
||
|
Capillary viscometer (7 piece in a group ) |
Group |
1 |
|
|
Rod type mercury thermometer |
Pc |
Each 1 |
|
|
( 0~50 ºC, 50~100 ºC,scale mark 0.1 ºC ) |
|
||
|
Plumb bob |
Pc |
1 |
|
|
Sensor |
Pc |
1 |
|
|
Bakelite cover |
Pc |
4 |
|
|
Clamps of capillary tube |
Pc |
4 |
|
|
Silica gel plug ( 3# ) |
Pc |
2 |
|
|
Fuse 10 A ( ะค6 × 30 ) |
Pc |
4 |
|
|
Round glass |
Pc |
1 |
|
|
Stopping ring of thermometer ( 1# ) |
Pc |
4 |
|
|
Line control timing button (connected by user) |
Pc |
1 |
|
|
Ear washing bulb |
Pc |
1 |
|
|
Manual Book |
Pc |
1 |
|
|
Certificate |
Pc |
1 |
|
|
Warranty card |
Pc |
1 |
|
|
Glycerol or mineral oil |
|
20 L |
Test temp. above 80 ºC |
|
Petroleum ether 60-90 ºC |
Analytical pure 500 ml |
1 bottle |
|
|
Distilled watter |
3 grade |
Some |
|
