Liquid Petroleum Products Hydrocarbon Tester SYD-11132 |
|||
|
Specifications |
|||
|
Power supply |
AC 220 V ±5 %,50 Hz |
||
|
Pressure regulating range of reducing valve |
( 0~400 ) kPa |
||
|
Electric agitator |
Independently controlled for each way |
||
|
Ultraviolet light source pipe |
1220 mm in length,wavelength is 365 mm ±5 nm |
||
|
Illuminating lamp |
1220 mm in length,power is 40 W |
||
|
Air supply |
Nitrogen cylinder ( or air compressor,compressed air bottle ) |
||
|
Ambient temp. |
( 5~35 ) ºC |
||
|
Relative humidity |
≤85 % |
||
|
Dimension |
350 × 400 × 1770 mm |
||
|
Maximum power consumption |
600 W |
||
|
Accessories & documents List |
|||
|
Name |
Unit |
Qty |
Memo |
|
SYD-11132 Liquid Petroleum Products Hydrocarbon Tester |
Set |
1 |
|
|
Precision inner diameter adsorption column |
Piece |
2 |
|
|
imported silica gel ( 500 g ) |
Bottle |
1 |
|
|
imported fluorescent indicator ( 4 g ) |
Bottle |
1 |
|
|
6 mm intake pipe ( intake pipe with cylinder connection ) |
Set |
1 |
|
|
Glass grinding plug ( with trachea ) |
Set |
2 |
|
|
Glass flow export |
Piece |
2 |
|
|
Grinding mouth clip ( 28, large ) |
Piece |
2 |
|
|
Grinding mouth clip ( 12, small ) |
Piece |
2 |
|
|
Indicate that the dose spoon |
Piece |
1 |
|
|
Special needle used for cleaning |
Piece |
1 |
When used for washing |
|
00 ml waste liquid bottle (with rubber stopper & PU tube) |
Set |
1 |
When used for washing |
|
Plastic measuring cup ( 250 ml ) |
Piece |
1 |
When used for washing |
|
Magnetic pointer |
Piece |
8 |
Placed on both sides of the scale |
|
Magnetic fixed base |
Piece |
2 |
When the vibration place the magnetic fixed basein the bottom of the absorption colum |
|
Fuse ( 10 A,ะค5 × 20 ) |
Piece |
2 |
Spare parts |
|
Purple light tube, 40 W, 365 nm wavelength |
Piece |
1 |
Spare parts, placed inside the instrument |
|
Sampler ( 1 ml injector with needle ) |
Piece |
1 |
|
|
Operation manual |
Piece |
1 |
|
|
Quality certificate |
Piece |
1 |
|
|
Product Warranty Card |
Piece |
1 |
|
