Model

RX-516

RX-517

Features

Dual range detection of HC in %vol and %LEL

Dual range detection of HC in %vol and %LEL

Unique gas combinations include : HC/O₂/H₂S

Unique gas combinations include : HC/O₂/H₂S 0-100.0 ppm & 0-1,000 ppm

Accurately measure HC from inerted tanks with infrared sensor

Accurately measure HC from inerted tanks with infrared sensor

Intrinsically safe design

High range H₂S 0-1,000 ppm available

Datalogging ( Max 30 hours of interval trend )

Intrinsically safe design

Specification

Category

Portable gas detector

Type

Multi gas

Sampling method

Sample draw

Type of alarm

Gas alarms, Trouble alarms

Display of alarm

Flashing light, buzzer

Explosion proof

Intrinsically safe

Approvals

ATEX, KIMM, MED

Power source

Alkaline batteries ( Size C ) 4 pcs.

Continuous operation

Approx. 30 hours ( no alarm, no light, at 25 ℃ )

Dimensions & Weight

Approx. 200 ( W ) x 80 ( H ) x 142 ( D ) mm

Approx. 1.8 kg ( including batteries )

Approx. 2.0 kg ( including batteries )

Operating temp. & Humidity

-10 ℃ to 50 ℃, Below 90% RH ( Non-condensing C17 )

-10 ℃ to 50 ℃, Below 90 % RH ( Non-condensing )
