Melting point apparatus Digital SMP10 & SMP20 Stuart

Supplied complete with calibration certificate showing individual serial number for traceability

Model

SMP10

SMP20

Number of samples

2

2

Temp. range

Ambient to 300 ºC

Ambient to 300 ºC

Temp. accuracy

± 1.0 ºC at 20 ºC, ± 2.5 ºC at 300 ºC

± 1.0 ºC at 20 ºC, ± 2.5ºC at 300 ºC

Display

Three digit LED

Four digit LED

Display resolution

1 ºC

0.1 ºC

Display hold facility

No

Yes

Ramp rates

20 ºC per minute to plateau, 2 ºC per minute to melt

20 ºC per minute to plateau, variable between 1 & 10 ºC per minute to melt

Dimensions ( W x d x H )

160 x 220 x 170 mm

160 x 220 x 170 mm

Net weight

1.8 Kg

1.8 Kg

Electrical supply

230 V, 50 Hz, 75 W

230 V, 50 Hz, 75 W

Melting point tubes

Made from soda glass, these tubes are easy to seal in a Bunsen flame and break into two. Supplied in robust tube

holder, pack of 100 tubes.

Tube overall length is 100 mm Tube diameter = 1.9 mm, inner diameter = 1.3 mm and wall thickness = 0.3 mm

Model

Description

SMP10

Melting point apparatus, 1 ºC resolution, complete with pack of 100 melting point tubes, closed at one end

SMP20

Melting point apparatus, 0.1 ºC resolution, complete with pack of 100 melting point tubes, closed at one end

SMP10/ 1

Glass melting tubes, closed at one end, pack of 100

SMP2/ 1

Glass melting tubes, closed at both ends, pack of 100

SMP1/ 4

Glass melting tubes, open at both ends, pack of 100
