| Specifications |
| Size |
4.6 x 3.0 ( 2.6 ) 3.0 x 0.9 in ( 117 x 76 ( 66 ) 74 x 24 mm ) |
| Weight |
7.03 oz ( 206 g ) ( including Li-ion battery and clip ) |
| Sensors |
LEL Catalytic bead for combustibles, Liquid Oxygen ( O2 ), Electrochemical Sensor for CO, H2S, HCN |
| Battery |
Rechargeable Li-ion |
| Running Time |
15 hours continuous non-wireless, 11 hours continuous wireless |
| |
Note: All battery specifications at 68 °F ( 20 °C ); lower temperatures and alarm conditions will affect runtime |
| Display Graphic |
Monochrome display, 1.73 x 1.29 in ( 44 x 33 mm ) with 2 color back light modes |
| Keypad |
Two-button operation |
| Direct ReadOut |
Real time reading of gas concentration and Man Down indicators |
| |
Multiple units display options |
| |
Wireless and GPS ON/OFF and reception quality |
| |
STEL, TWA, peak, and minimum values |
| |
Intelliflash and policy enforcement indicators |
| Alarms |
Multi-tone 100dB buzzer ( at 11.8"/ 30 cm, typical ), vibration alarm, and flashing LEDs and on-screen |
| |
indication of alarm conditions |
| |
Alarms: latching, non latching or manual override |
| |
Additional diagnostic alarm and display message for low battery |
| |
Wireless connectivity alarm |
| |
Man Down Alarm and real-time remote wireless notification |
| Datalogging |
Continuous datalogging ( 6 month for 4 sensors at 1-minute intervals ) |
| |
User-configurable datalogging intervals ( from 1 to 3,600 seconds ) |
| Communication & Data Download |
Data download and instrument set-up and upgrades on PC via Travel Charger |
| Wireless data and status transmission via built-in RF modem ( optional ) |
| Wireless Network |
RAE Dedicated Wireless Mesh network or Standard WiFi |
| Wireless Range ( Typical ) |
Up to 650 ft ( 200 m ) for sub1GHz Mesh Radio3, Up to 330 ft ( 100 m ) for WiFi3, Up to 15 ft ( 5 m ) for BLE |
| EMC/RFI |
EMC directive: 2004/108/EC |
| IP Rating |
IP-67 |
| Calibration |
Two-point calibration ( manual, or automatic with AutoRAE 2 ) |
| Safety Certifications |
US & Canada: Class I, Division 1, Groups A, B, C and D |
| |
II 2G Ex ia d IIC T4 Gb |
| |
I M1 EX ia I Ma |
| Temperature |
-4° to 140 °F ( -20° to 60 °C ) for T4 temperature code |
| Humidity |
0 % to 95 % relative humidity ( non-condensing ) |
| Attachmeants |
Stainless-steel alligator clip: wrist wrap ( optional ) |
| Warranty |
2-year warranty on device and sensors2 |
| Model Number |
PGM26XX |
| Wireless |
ISM license free band. IEEE 802.15.4 Sub 1 GHz, IEEE 802.11 bands b/g 2.4 GHz |
| Wireless Approvals |
FCC Part15, CE R&TTE, Bluetooth 4.0, GPS, Others4 |
