Microtitre plate shakers - SSM5 & SSL5 Stuart
Specifications
Model	SSM5	SSL5
Platform dimensions ( w x l )	220 x 220 mm	306 x 306 mm
Number of plate positions	4	8
Speed range	250 - 1250 rpm	250 - 1250 rpm
Orbit diameter	1.5 mm	1.5 mm
Maximum load	1 Kg	2 Kg
Operational temperature	+4 to +40 °C	+4 to +40 °C
Maximum permissible humidity	80 %	80 %
Overall dimensions ( w x d x h )	240 x 300 x 160 mm	360 x 420 x 160 mm
Electrical supply	230 V, 50 Hz, 50 W	230 V, 50 Hz, 50 W
Model	Description
SSM5	Shaker, microtitre, mini
SSL5	Shaker, microtitre, labscale
SSM5/1	Tube holder for 1.5 ml tubes
SSM5/2	Tube holder for 0.5 ml tubes
SSM5/3	Tube holder for 0.2 ml tubes
