MLR-352H-PE Climate Chamber Panasonic

Specifications

Model

MLR-352-PE

MLR-352H-PE

External Dimensions ( W x D x H)

760 x 700 x 1835 mm

760 x 700 x 1835 mm

Internal Dimensions ( W x D x H )

520 x 490 x 1135 mm

520 x 490 x 1135 mm

Volume

294 liters

294 liters

Net Weight

226 kg

235 kg

Temp. Control Range & Fluctuation

0 ~ +50 ( lamp off ) ±0.3 °C

0 ~ +50 ( lamp off ) ±0.3 °C

+10 ~ +50 ( lamp on ) ±0.3 °C

+10 ~ +50 ( lamp on ) ±0.3 °C

Temp. Uniformity

±1 °C ( lamp off )

±1 °C ( lamp off )

±2.5 °C ( lamp on )

±2.5 °C (lamp on)

Humidity Level & Fluctuation

N/A

60~90 % RH / LS:0 ( 15~45 ºC )

55~85 % RH / Lamp On ( 15~45 ºC )

Light Control Range

Programmable 0 ~ 20000

Programmable 0 ~ 20000

Temperature Sensor

Thermistor

Thermistor

Display

LCD

LCD

Exterior Material

Painted Steel

Painted Steel

Interior Material

SS SUS-304

SS SUS-304

Insulation Material

PUF

PUF

Outer Doors

3

3

Outer Door Lock

N

N

Field Reversible Door

-

-

Inner Doors

1

1

Shelves

5

5

Shelf Dimensions ( W x D x H )

-

-

Max. Load Per Shelf

25 kg

25 kg

Max. Shelf Capacity

100

100

Access Port

1

1

Access Port Position

Ceiling

Ceiling

Access Port Diameter

40

40

Power Failure

R

R

Out of Temperature Setting

B-R

B-R

High Temperature

B-R

B-R

Out of Humidity Setting

N/A

V

Door Open

V-B

V-B

Power Supply

230 V

230 V

Frequency

50 Hz

50 Hz

Noise Level

45 dB

45 dB

Accessories

Digital Interface

MTR-480-PW

MTR-480-PW
