Moisture Analyzers DLB 160-3A Kern

Specification

KERN

DLB 160-3A

Readout [d]

0,001 g / 0,01 %

Weighing range [Max]

160 g

Reproducibility, weight of sample 10 g

0,05 %

Display after drying ( Display can be switched over at any time )

Moisture [%] = Weight loss

0 - 100 %

( WL ) from SW ( startweight )

Dry mass [ % ] = Residual weight ( RW ) from SW

100 - 0 %

ATRO [ % ]  ( SG  : RG ) · 100%

100 - 999 %

Weight loss [ g ] ( WL )

Absolute value in [g]

Temperature range

35 °C - 160 °C in steps up to 1 °C

Drying modes

• Standard drying

• Pre-heat level, can be switched on

Switch off criteria

• When the set time has expired ( 1 - 99 min )

• When the weight loss per unit of time falls below the target value ( 60 sec )

Recall of measurement

• Continuous output ( residual weight )

• At the end of the drying process, manual or automatic

( only in connection with KERN YKB-01N printer or PC )

Overall dimensions WxDxH

210 x 340 x 225 mm

Net weight

approx. 4,2 kg

Option DKD Calibr. Certificate

963-127
