Motorized Atterberg Liquid Limits Machine Gilson |
|
Motorized Atterberg Liquid Limits Machine w/Counter (115V / 60Hz) Model : SA-60 |
|
Motorized Atterberg Liquid Limits Machine w/ Counter (230V / 50Hz) Model : SA 60F |
|
Hand-Operated Atterberg Liquid Limits Machine Model : SA-61 |
|
Hand- Operated Atterberg Liquid Limits Machine w/Counter Model : SA-62 |
|
Description |
|
Liquid Limit is the water content at which soil changes from a liquid to a plastic state, defined as a point where two halves of a soil sample flow together when jarred 25 times in a specified manner using a Liquid Limit machine. |
|
Gilson offers motorized or hand-crank operated machines with either an automatic impact counter, or a cost-effective hand-crank model without counter. All models consist of a brass cup and carriage designed to control drop exactly 1cm onto a hard rubber base. Height of drop is adjusted by a nut at the rear of the cup carriage using the gauge at one end of the included plastic Casagrande Grooving Tool. The cup attaches to the carriage by a pin, for easy removal when cleaning or inspecting. All mechanical parts are machined from solid brass and rubber feet isolate the base from the work surface. |
|
SA-60 Motorized Liquid Limit Machine with counter is most accurate with use of a special geared motor assuring proper operating speed of 1.9—2.1 drops per second. An on-off switch is provided. |
|
SA-61 Hand Operated Liquid Limit Machine does not have a counter and is a more economical option. |
|
SA-62 Hand Operated Liquid Limit Machine with counter offers a more automated, cost-effective option. |
|
Features |
|
Variety of motorized or hand-crank options to fit your application and budget |
|
Complete control of drop to 1cm |
|
Easily removable cup for cleaning or inspection |
|
Included Items |
|
SA-60 Motorized Liquid Limit Machine |
|
Or |
|
SA-61 Hand-Operated Liquid Limit Machine |
|
Or |
|
SA-62 Hand-Operated Liquid Limit Machine with Counter |
|
Plastic Casagrande Grooving Tool |
|
Optional Accessories |
|
SA-66 Glass Plate |
|
SAA-10P ASTM Liquid Limit Grooving Tool, Plastic-Casagrande |
|
SAA-11 Liquid Limit Machines, Brass Cup with Mounting Holes |
|
SAA-8 AASHTO Liquid Limits, Grooving Tool |
|
SA-65 Accessory Set for Liquid/Plastic Limits |
|
SAA-10 ASTM Liquid Limit Grooving Tool, metal-Casagrande |
|
SAA-12 Liquid Limits Machines, Brass Cup with Holder |
|
Meets Standard ( s ) |
|
AASHTO T 89 , AASHTO T 90 , ASTM D4318 |
|
Specifications |
|
SA-60 , SA-60F Dimensions 12 x 7.5 x 6 in ( 305 x 191 x 152 mm ), L x W x H Estimated Shipping Weight, lb ( kg ) 16 ( 7 ) |
|
SA-61 Dimensions 6.5 x 6 x 5 in ( 165 x 152 x 127 mm ), L x W x H Estimated Shipping Weight, lb ( kg ) 5 ( 2 ) |
|
SA-62 Dimensions 6.5 x 7 x 5 in (165 x 178 x 127 mm), L x W x H Estimated Shipping Weight, lb ( kg ) 5 ( 2 ) |
|
Meets Standard ( s ) |
|
AASHTO T 89 , AASHTO T 90 , ASTM D4318 |
