Gallet F1 SF Helmet MSA

Size

Size M : 52–62 cm/Size L : 57–65 cm

Head sizes between 58 and 62 should select the best suited size through fitting test

Weight ( basic configuration )

Size M – 1450 g ( ± 30 g )/Size L – 1550 g ( ± 30 g )

Colours

White, Yellow, Red, Black, Hi-Viz Yellow, Hi-Viz Orange, Grey, Blue, Green, Photoluminescent

CE Marking according to EN443 :2008 “Helmets for fire-fighting in buildings and other structures” Type B – Full coverage shell

Approvals

Optional requirements: C – Resistance to chemicals/–30 °C ( *** ) – Very low temperatures/3b – Coverage of front area 3 b ( through face shield)/E2 – Wet helmet insulation/E3 – Surface insulation ( depending on front plate model )

Material ( shell )

High Temperature Thermoplastic material, injection molded

Material ( impact liner )

Shock absorbing polyurethane foam, with over molded aramide reinforcement

Chinstrap

3 points, adjustable chinstrap with release buckle

Interior

Flame resistant, padded headband and chinstrap covers, made of Nomex or Leather

Face Shield

Clear or gold coated face guard visor

Face shield material

Coated thermoplastic material, high temperature performance

CE marking according to EN14458 “High performance visors” – Face guard

Face shield approvals

Optional requirements/Use for Fire-fighting/N – Antifog/K – Antiscratch/Ω – Electrical properties ( Surface insulation )

Ocular Visor

Material

Clear Polycarbonate

Weight

100 g ± 10 g

Approvals

EN14458 – Eyeguard with following optional requirements/K – Antiscratch/Ω – Electrical properties ( Surface insulation )/ T – Extreme of Temperatures (–30 °/+120 °C )/UV Filter to EN170 (2–1.2)

Neck curtains

Material

Aluminized fabric, Impregnated nomex or wool/nomex complex

Weight

90 g ( neck only ) to 150 g ( integral )

Approvals

Tested to radiant heat, flame engulfment, molten metals and chemical splashes ( EN443:2008 – area 3 a )

Integrated lighting module

Weight

100 g ± 10 g

Light source

4 white LEDs with optimal short range coverage

Batteries

3 x AAA batteries ( disposable or rechargeable )

Approvals

CE marking with ATEX approval ( Gas and Dust )/2G Ga Ex ia IIC T4/T3 – 2D Da Ex iaD 20 IP56

Order Information

F1SF painted standard helmets EN443 CE GA2300*(1)(2) : With 9 % gold face shield and eye screen, 3 points fire proof chinstrap with automatic buckle GA2301*(1)(2) : With 43 % gold face shield and eye screen, 3 points fire proof chinstrap with automatic buckle. GA2302*(1)(2) : With transparent face shield and eye screen, 3 points fire proof chinstrap with automatic buckle.

F1SF painted Ratchet helmets EN443 CE GA2350*(1)(2) : With 9 % gold face shield and eye screen, 3 points fire proof chinstrap with automatic buckle GA2351*(1)(2)  : With 43 % gold face shield and eye screen, 3 points fire proof chinstrap with automatic buckle. GA2352*(1)(2) : With transparent face shield and eye screen, 3 points fire proof chinstrap with automatic buckle.

F1SF Nickel helmets EN443 CE  GA2400*(1)(2) : Standard cradle, with 9 % gold face shield and eye screen, 3 points fire proof chinstrap with automatic buckle GA2450*(1)(2) : Ratchet cradle, with 9 % gold face shield and eye screen, 3 points fire proof chinstrap with automatic buckle (1) Helmets colour references : Nickel= BJ, White=BH, Red=RE, Photoluminescent=VF, Black=NJ, Blue=IT, Yellow=JD, Orange=OB, Grey=NM, Green=VR (2) Front plates colour references : Black=16, Nickel=04, Varnished

Cleaning and Protection GA1616 : Clear pilot screen cleaner for face shield GA1305 : Cleaner Poli F1 for nickel helmet GA1043 : Protective bag for F1 helmet Customisation GA1104xx : Reflective stickers Specific front plates : on request

Performances EN443 : 1997 compliance 14 kW/m2, -20/-30 °C, E2/E3.

Standard

GAA1121100000-BH16

F1SF EN443:2008 CE,Ratched headband,Clear Faceshield,Neckcurtain Aluminized+Nomex

GAA1121100000-RE16

F1SF EN443:2008 CE,Ratched headband,Clear Faceshield,Neckcurtain Aluminized+Nomex

GAA1221100000-BH16

F1SF EN443:2008 CE,Ratched headband, Clear, Asian, Neckcurtain, White-16

GAA1221120300-RE16

F1SF EN 443:2008 CE, Red,Ratched headband,Clear faceshield EN14458,Asian eyeshield,Neckcurtain Alumi

GAA1221130300-RE16

F1SF EN 443:2008 CE, Red,Ratched headband,Clear faceshield EN14458,Asian eyeshield,Neckcurtain Alumi

GAA2111100000-RE32

F1SF EN 443 2008CE Standar headband,Gold coated Faceshield, Standar Internal visor, Neckcu

GAA2221100000-BH16

F1SF EN443:2008 CE,Ratched headband,Gold coated Faceshield,Asian eyeshield,Neckcurtain Aluminized

GAA2221100000-JD16

F1SF EN 443:2008 CE, Yellow (plain),Ratched headband,Gold coated faceshield EN14458,Asian eyeshield,

GAA2221100000-OB16

F1SF EN443:2008 CE,Ratched headband,Gold coated Faceshield,Asian eyeshield,Neckcurtain Aluminized

GAA2221100000-RE16

F1SF EN443:2008 CE,Ratched headband,Gold coated Faceshield,Asian eyeshield,Neckcurtain Aluminized

SEA00000016

F1SF EN 443:2008 CE, Red,Ratched headband,Gold coated faceshield EN14458,Asian eyeshield,Integral Ne

SEA00000088

F1SF EN 443:2008 CE, Red,Ratched headband,Clear faceshield EN14458,Asian eyeshield,Neckcurtain Alumi

SEA00000095

F1SF EN 443:2008 CE, Red,Ratched headband,Clear faceshield EN14458,Neckcurtain Aluminized+Nomex , Fr

SEA00000097

F1SF EN 443:2008 CE, Red,Ratched headband,Gold coated faceshield EN14458,Asian eyeshield,Neckcurtain

SEA00000098

F1SF EN 443:2008 CE, Orange (fluo),Ratched headband,Gold coated faceshield EN14458,Asian eyeshield,N

SEA00000277

F1SF EN 443:2008 CE, Red,Ratched headband,Clear faceshield EN14458,Asian eyeshield,Neckcurtain Alumi

SEA00000278

F1SF EN 443:2008 CE, metalized,Ratched headband,Gold coated faceshield EN14458,Asian eyeshield,Neckc

SEA00000425

F1SF EN 443:2008 CE, Red,Ratched headband,Clear faceshield EN14458,Asian eyeshield,Neckcurtain Wool+

SEA00000589

Configures F1SF Gallet Helmet

SEA00000597

Configures F1SF Gallet Helmet

SEA00000598

Configures F1SF Gallet Helmet

SEA00000633

Configures F1SF Gallet Helmet

Composition

■ Shell : Injected thermoplastic material with attachment points for face shield, eye screen, customisable front plate.

■ Padding : Rigid padding for superior shock absorption and thermal protection, soft foam padding for comfort and stability.

■ Inner elements : net vented cradle, adjustable in depth. 2 versions
- Standard net cradle with adjustable headband
- Ratchet patented cradle with quick adjustment system

■ Chinstrap : 3 points fire proof chinstrap, with possibility to adjust the angle of the strap for perfect comfort, even when wearing mask. The third point provides increased stability.

■ Mask attachment : The F1SF helmets features adjustable SCBA mask adapters ( KitFix )

■ Built-in interface : the F1SF includes interfaces for accessories ( ex: lamp ) on both sides for maximum flexibility Characteristics Sizes : 53 to 63 cm with a ratchet cradle 53 to 63 cm with a standard cradle Weight : 1450 g ( ± 50 g ) Colors : White, Yellow, red, black, blue, photoluminescent, orange, grey.
