Multi-Room Incubator WIM Forced Convection WIM-4,WIM-R4,WIM-RL4 Daihan Scientific

Specification

Model

Ambient +5 ℃ ~ 70 ℃

0 ℃ to 70 ℃

0 ℃ to 70 ℃

“WIM-4”

“WIM-R4”

with illumination “WIM-RL4”

Circulation

Forced Convection-Blower FAN

Capacity

125 Lit. × 4 Rooms

Illumination

None

FRL 55 W × 2 ( × 4 Rooms )

Temp.

Range

Ambient +5℃ ~ 70℃

0℃ to 60 ℃

Accuracy

±0.2 ℃ at 37 ℃

Uniformity

±0.3℃ at 37℃,

± 0.5 ℃ at 37 ℃

±0.7℃ at 50℃

Sensor

PT100

Heat-up Time

15 min. to 37 ℃

20 min. to 37 ℃

30 min. to 50 ℃

30 min. to 50 ℃

Recovery Time

8 min. to 37 ℃

10 min. to 50 ℃

( Door open 30 sec )

10 min. to 50 ℃

12 min. to 50 ℃

Heating Power / Consumption

500 W × 4 ea

650 W × 4 ea

Compressor

None

1/4 HP ( × 4 Rooms )

Timer & Alarm

99 hr 59 min ( with delay / Continuous run.), Error status & Timer-end

Display

Digital LCD with Back - Light Function

Controller

Digital Fuzzy Controller with Jog-Shuttle Switch ( Turn & Push )

Inner Door

with 4 ea of Inner Tempered Glass Door

Shelves

Included 8ea of Teflon Coated steel Shelves ( 2 ea × 4 Chambers )

Permitted Total Load

Total Load 128 kg ( 16 kg × 8 Shelves )

Safety Circuit

Over Temp. and Over Current Protector, Sensor Error Detector

Material

Internal : Stainless steel ( ＃304 ),   External : Powder Coated steel

Dimension

( W x D x H )

Interior

500 × 500 × h500 mm ( × 4 Rooms )

Exterior

1,655 × 845 × h1,710 mm

Net Weight

343 kg

350 kg

Packing Size ( W x D x H )

1,900 × 1,050 × 1,950 mm

Gross Weight

441 kg

450 kg

Power Consumption

2.6 kW

4.5 kW

4.8 kW

Power Supply

1 Phase, AC 120V, 60Hz or AC 230V, 50/60Hz

1 Phase AC 120V, 60Hz or AC 230V,50/60Hz or 3 Phase 380V, 50/60Hz
