Macro 900 Multiparameter PT1401 Palintest
Combining an intuitive user interface with a suite of advanced software tools including GPS mapping and trending data, the Macro 900 is the highest specification instrument in the range. The system can be configured to meet individual requirements by customising the kit with a range of optional ion-selective electrodes and optical probes:
Constructed from annodised aluminium and featuring a protective sleeve, the probes are protected from the environment
Fully customisable for your application - select ISE and optical probes
Guaranteed long life with Kevlar cables connecting your IP67 rated meter to the probe
Store 1000 data sets, including GPS data to allow for ensuing visual analyses of a survey area.
The Macro 900 is a modular, customisable system so there is not one set part code for this kit. Use the 'Make my Macro' document in the Resources section below to view the range of configurations available, and contact a Sales Representative to receive a quotation.
Specification
D O Range	0 - 500 %, 0 - 50 mg/L
D O Resolution	0.1 %, 0.01 mg/L
D O Accuracy	0 - 200 %, ± 1 % of reading
Cond Range	0 - 200 mS/cm ( 0 - 200,000 μS/cm )
Cond Resolution	0 - 9999 μS/cm, 10.00 - 99.99 mS/cm, 100.0 - 200.0 mS/cm
Cond Accuracy	± 1 % of reading or ± 1 μS/cm ( if greater )
TDS Range	0 - 100,000 mg/L
TDS Resolution	0 - 9999 mg/L, 10.00 - 100.00 g/L
TDS Accuracy	± 1 % of reading or ± 1 mg/L ( if greater )
Resistivity Range	5 Ωcm - 1 MΩcm
Resistivity Resolution	5 - 9999 Ωcm, 10.0 - 1000.0 KΩcm
Resistivity Accuracy	± 1 % of reading or ± 1 Ωcm ( if greater )
Salinity Range	0 - 70.00 ppt
Salinity Resolution	0.01 ppt
Salinity Accuracy	± 1 % of reading or ± 0.1 unit of reading
Seawater Spec Gravity Range	0 - 50 st
Seawater Spec Gravity Resolution	0.1 st
Seawater Spec Gravity Accuracy	± 1.0 st
pH Range	0 - 14 pH ( ± 625 mV )
pH Resolution	0.01 pH ( ± 0.1 mV )
pH Accuracy	± 0.01 pH ( ± 5 mV )
ORP Range	± 2000 mV
ORP Resolution	0.1 mV
ORP Accuracy	± 5 mV
Temp. Range	-5°C – 50°C
Temp. Resolution	0.1°C
Temp. Accuracy	± 0.5°C
Depth Range	0 - 30 m
Depth Resolution	0.01 m
Depth Accuracy	± 0.1 m
