Multiparameter Water Quality Meter Hanna Instrument

HI9829 Multiparameter pH/ISE/EC/DO/Turbidity Waterproof Meter with GPS option

Specifications

pH Range

0.00 to 14.00 pH

pH Res

0.01 pH

pH Accu

±0.02 pH

mV Range

±600.0 mV

mV Res

0.1 mV

mV Accu

±0.5 mV

ORP Range

±2000 mV

ORP Res

0.1 mV

ORP Accu

±1.0 mV

ORP Cali

Automatic at one custom point ( relative mV )

EC Range

0 to 200 mS/cm ( absolute EC up to 400 mS/cm )

EC Res

1 µS/cm; 0.001 mS/cm; 0.01 mS/cm; 0.1 mS/cm; 1 mS/cm

EC Accur

±1 % of reading or ±1 µS/cm whichever is greater

EC Cali

Automatic 84 µS/cm, 1413 µS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 111.8 mS/cm )

TDS Range

0 to 400000 ppm ( mg/L ); ( the maximum value depends on the TDS factor )

TDS Res

Manual : 1 ppm ( mg/L ); 0.001 ppt ( g/L ); 0.01 ppt ( g/L ); 0.1 ppt ( g/L ); 1 ppt ( g/L )

TDS Accu

±1 % of reading or ±1 ppm ( mg/L ), whichever is greater

Resistivity Range

0 to 999999 Ω•cm; 0 to 1000.0 kΩ•cm; 0 to 1.0000 MΩ•cm

Res.Res

Dependent on resistivity reading

Res. Cali

based on conductivity calibration

Salt Range

0.00 to 70.00 PSU

Salt Res

0.01 PSU

Salt Accu

±2 % of reading or ±0.01 PSU whichever is greater

Seawater σ Range

0.0 to 50.0 σt, σ₀, σ₁₅

Seaw σ Res

0.1 σt, σ₀, σ₁₅

Seaw σ Accur

±1 σt, σ₀, σ₁₅

Ammonium-Nitrogen Range

0.02 to 200.0 ppm Am ( as NH4 +-N )

Am-Nit. Res

0.01 ppm to 1 ppm 0.1 ppm to 200.0 ppm

Am-Nit Accu

±5 % reading or 2 ppm

Am-Nit Cali

1 or 2 point, 10 ppm and 100 ppm

Chloride Range

0.6 to 200.0 ppm Cl ( as Cl- )

Chl Res

0.01 ppm to 1 ppm 0.1 ppm to 200.0 ppm

Chl Accu

±5 % of reading or 2 ppm

Chl Cal

1 or 2 point, 10 ppm and 100 ppm

Nitrate-Nitrogen Range

0.62 to 200.0 ppm Ni ( as NO3 - -N )

N. Res

0.01 ppm to 1 ppm 0.1 ppm to 200 ppm

N. Accu

±5 % of reading or 2 ppm

N. Cal

1 or 2 point, 10 ppm and 100 ppm

Turbidity Range

0.0 to 99.9 FNU; 100 to 1000 FNU

Turbidity Res

0.1 FNU from 0.0 to 99.9 FNU 1 FNU from 100 to 1000 FNU

Turbidity Accu

±0.3 FNU or ±2 % of reading, whichever is greater

Turbidity Cali

Automatic 1, 2, or, 3 points at 0, 20 and 200 FNU, or custom

DO Range

0.0 to 500.0 %; 0.00 to 50.00 ppm ( mg/L )

DO Resolution

0.1 %; 0.01 ppm ( mg/L )

DO Accuracy

0.0 to 300.0 % saturation : ±1.5 % of reading or ±1.0 %

Atmospheric Pressure Range

450 to 850 mm Hg; 17.72 to 33.46 in Hg; 600.0 to 1133.2 mbar; 8.702 to 16.436 psi

Atm.Press. Res

0.1 mm Hg; 0.01 in Hg; 0.1 mbar; 0.001 psi; 0.0001 atm; 0.01 kPa

Atm.Press. Accu

±3 mm Hg within ±15 °C from the temperature during calibration

Atm.Press. Cal

Automatic at one custom point

Temp. Range

-5.00 to 55.00 °C, 23.00 to 131.00 °F, 268.15 to 328.15 K

Temp. Res

0.01 K, 0.01 °C, 0.01 °F

Temp. Accu

±0.15 °C; ±0.27 °F; ±0.15 K

Temp. Cali

Automatic at one custom point

Temp. Comp

Automatic from -5 to 55 °C ( 23 to 131 °F )

Logging Memory

44,000 records

Logging Interval

One second to three hours

PC Connectivity

USB ( with HI 929829 software )

Battery Type/Life

1.2 V ( 4 ) NiMH, rechargeable batteries, size C type

Waterproof Protec

IP67

Environment

0 to 50 °C ( 32 to 122 °F ); RH max 100 %

Dimensions

221 x 115 x 55 mm (8.7 x 4.5 x 2.2”)

Weight

750 g (26.5 oz.)

GPS

12 channel receiver 10 m (30 ft) accuracy
