Specification
| Model | SH-WB-10GDH | SH-WB-20GDH | SH-WB-40GDH |
| Temp Range | Ambient +10 °C to 300 °C ( Ambient +18 °F to 572 °F ) | ||
| Temp Controller | Digital P I D Controller | ||
| Capacity | 13 L | 24 L | 48 L |
| Demension Internal |
250 × 300 ×170 mm | 350 × 400 × 170 mm | 600 × 400 × 200 mm |
| ( W x D x H ) | 9.84 x 11.81 x 6.69 inch | 13.78 x 15.75 x 6.69 inch | 23.62 x 15.75 x 7.87 inch |
| Demension External | 635 x 385 x 345 mm | 732 x 485 x 345 mm | 1035 x 500 x 390 mm |
| ( W x D x H ) | 25.00 x 15.15 x 13.58 inch | 28.81 x 19.09 x 13.58 inch | 40.74 x 19.68 x 15.35 inch |
| Weight | 21 Kg | 29 Kg | 38 Kg |
| Material Internal | Stainless Steel | ||
| Material External | Steel Plate With Powder Heating Coated | ||
| Heater Capacity | 2 KW | 3.5 KW | 4.8 kW |
| Electrical 120 V ,50/60 Hz, 1Φ | 17.3 A | 30.7 A | 44.1 |
| Electrical 230 V,50/60 Hz, 1Φ | 9.0 A | 16.0 A | 23.0 A |
