| Features | |
| SMART interface with Android | |
| - Wi-Fi / Bluetooth | |
| - Google cloud print | |
| - E-mail push : e-mail measurement data on the field | |
| - Tablet PC approach | |
| - PDF, Excel transformation | |
| - USB host : keyboard, mouse connectable | |
| - Multi languages support | |
| - Voice guide | |
| SMART Design | |
| - Double beam optic system | |
| - Smallest size in the same level | |
| - 10.1inches LCD resolution 1360 X 768 | |
| - 8 position multi cell holder | |
| - Multi touch LCD screen | |
| - Auto slide cell box door | |
| - Free warranty on lamps : 2 years or 2,500 hours free warranty on deuterium | |
| lamp and 4,000 hours free warranty on tungsten lamp. | |
| - Free voltage system | |
| -Quartz over-coating | |
| A. System configuration | |
| UV-Vis spectrophotometer ( OPTIZEN α ) | |
| Quartz Cell - 3.5ml / path length 10mm | |
| Operating Manual | |
| B. Hardware Specification | |
| UV-Vis spectrophotometer | |
| Photometric system | Double Beam Optics |
| Spectral band width | < 1.0 nm |
| Wavelength range | 190 - 1100 nm |
| Wavelength accuracy | ＜±0.5 nm ( at D2 Peak 656.1 nm, 486.0 nm ) |
| Wavelength repeatability | ±0.1 nm |
| Wavelength slew rate | about 7,000 nm / min |
| Scan Speed | Max 4,000 nm / min |
| Photometric display range | - 4.0 ~ 4.0 A |
| Photometric accuracy | ± 0.005 A ( at 1.0 Abs) |
| Photometric reproducibility | ± 0.003 A ( at 1.0 Abs ) |
| Stray right | < 0.05 %T at 220 and 340 nm |
| baseline stability | ≤ ± 0.001 A/h ( at 550 nm ) |
| baseline flatness | ≤ ± 0.002 A ( 200 ~ 1100 nm ) |
| Light Source | Tungsten-halogen lamp and Deuterium lamp |
| Monochromator | Modified Czerny-turner type with 1200 lines/nm |
| Display | 10.1 inch LCD touch screen |
| Standard cell holder | Automatic rotary type 8-position multi-cell holder |
| Interface ports | USB port / Wi-Fi direct & Bluetooth |
| Data capacity | 2 GB ( 2 GB for OS ) |
| Detector | Silicone Photodiode |
| Power requirement | Free Voltage |
| Dimension | W 450 x D 430 x H 180 |
| Weight | 12 kg |
| Operating system | Android |
| C. Software Description | |
| Built in software | |
| - ABS/%T/Conc. With STC | |
| - Standard curve | |
| - Survey scan | |
| - Simple Kinetics | |
| - online S/W upgrade | |
