Orbital Shakers - SSM1 & SSL1 Stuart

Specifications

Model

SSM1

SSL1

Shaking action

Orbital

Orbital

Platform dimensions ( w x l )

220 x 220 mm

335 x 335 mm

Speed range

30 to 300 rpm

30 to 300 rpm

Orbit / amplitude

16 mm

16 mm

Maximum load

3 kg

10 kg

Overall dimensions ( w x d x h )

240 x 300 x 140 mm

360 x 420 x 270 mm

Operational temperature range

+4 to +40 °C

+4 to +40 °C

Maximum permissible humidity

80 %

80 %

Net weight

5 kg

11 kg

Electrical supply

230 V, 50 Hz, 50 W

230 V, 50 Hz, 50 W

Model

Description

SSM1

Shaker, orbital, mini

SSM1/1

Accessory cradle with 4 securing bars

SSM1/2

Large platform ( 340 x 300 mm, holds up 8 plates )

SSM1/3

Clear Acrylic lid

SSL1

Shaker, orbital, lab scale

SSL1/1

Accessory platform 510 x 510 mm with six rubber

SSL1/2

Large flat platform, no cradle for SSL1
