Specification
| Model | SH-DO-54FG | SH-DO-100FG | SH-DO-149FG | SH-DO-250FG |
| Air Circulation | Forced | |||
| Temp Range | Ambient +10 °C to 250 °C ( Ambient +18 °F to 482 °F ) | |||
| Time Range | 00.00 to 99 HR 59 MIN ( MIN SEC ) Selectable Digital Counter Timer | |||
| Temp & Time controller | Microprocess PID Membrane Touch Digital controller | |||
| Heater Capacity | 800 W | 1600 W | 2000 W | 3000 W |
| Demension Internal,mm | 380 × 340 × 420 | 480 × 400 × 530 | 555 × 450 × 600 | 700 x 450 x 800 |
| ( W x D x H ) inch | 14.96 x 13.39 x 16.54 | 18.90 x 15.75 x 20.87 | 21.85 x 17.72 x 23.62 | 27.56 x 17.72 x 31.50 |
| Demension External,mm | 500 × 630 × 760 | 600 × 690 × 870 | 675 × 740 × 940 | 820 × 740 × 1140 |
| ( W x D x H ) inch | 9.68 x 24.80 x 29.92 | 23.62 x 27.16 x 34.25 | 26.57 x 29.13 x 37.01 | 32.28 x 29.13 x 44.88 |
| Net Weight | 49 Kg | 64 Kg | 73 Kg | 104 Kg |
| Capacity | 54 L | 100 L | 150 L | 250 L |
| Material Internal | Stainless Steel | |||
| Material External | Steel Plate With Powder Heating Coated | |||
| Shelves | Stainless Wire, 2 Supplied ( 12 Maximum ) | |||
| Electrical 120 V ,50/60 Hz, 1Φ | 7.3 A | 14.5 A | 18.2 A | 27.3 A |
| Electrical 230 V,50/60 Hz, 1Φ | 3.5 A | 8.7 A | 8.7 A | 13.0 A |
