Convection Ovens Eyela Model  NDO-420, NDO-420W, NDO-520,  NDO-520W

Convection oven Programmable Eyela Model NDO451SD, NDO601SD

Convection Oven Eyela Model  NDO-401, NDO-401W, NDO-501, NDO-501W

Specification

Product Name Convection Oven

Model

NDO-420

NDO-420W

NDO-520

NDO-520W

No

252240

252250

252260

252270

Air circulation

Natural convection

Temp. control range

RT+10～300 ℃

RT+10～270 ℃

RT+10～300 ℃

RT+10～270 ℃

Temp. control accuracy

±1 ℃

Operation temp. range

40～250 ℃

Temp. distribution ( at 270 ℃ )

10 ℃ deviation

11 ℃ deviation

9 ℃ deviation

9 ℃ deviation

Max. temp. reaching time

90 min

60 min

130 min

90 min

Temp. control

P.I.D control

Temp. setting & display

Sheetkey input・Digital display

Timer function

Auto start, Auto stop, Auto start/stop, 1 step・2 step mode

Safety functions

Door open alarm, Sensor alarm, Upper/lower temp. limit alarm, Leak/overcurrent braker, Independent variable overheat protector, SSR malfunction

Heater

1.0 kW

1.2 kW

Temp. sensor

Pt100Ω

Chamber dimensions

450 W x 450 D x 450 H mm

600 W x 500 D x 500 H mm

Chamber capacity

91 L

150 L

Chamber material

SUS 304

Shelf

2 pcs

3 pcs

Shelf pitch & step

30 mm 11 steps

30 mm 13 steps

Observation window

-

250 W x 280 H

-

250 W x 280 H

Overall dimensions

550 W x 590 D x 811 H mm

700 W x 641 D x 861 H mm

Weight

56 kg

55 kg

58 kg

Power source

AC100 V 11A 1.1 kVA

AC100V 13A 1.3 kV
