Overhead Stirrers - SS10, SS20 & SS30 Stuart

Specifications

Model

SS10

SS20

SS30

Speed range

100 to 2000 rpm

100 to 2000 rpm

50 to 500 rpm / 100 to 2000 rpm

Maximum viscosity

10,000 mPas

20,000 mPas

40,000mPas

Torque at chuck

15 Ncm

27 Ncm

9027 Ncm

Chuck range

1.5-13 mm dia.

1.5-13 mm dia.

1.5-13 mm dia.

Hollow shaft

No

3-8mm dia.

3-8mm dia.

Dimensions ( w x d x h )

85 x 175 x 230 mm

85 x 195 x 230 mm

85 x 195 x 230 mm

Net weight

2.7 kg

3.2 kg

3.8kg

Electrical supply

230V, 50/60 Hz, 50 W

230V, 50/60Hz, 80W

230V, 50/60Hz, 80W

Model

Description

SS10

Overhead stirrer, general purpose

SS20

Overhead stirrer, high performance

SS30

Overhead stirrer, dual torque
