Parker icount Oil Sampler ( IOS ) Kittiwake
Specifications
Product start-up time	10 seconds minimum
Measurement period	Default 30 seconds run time; 15 seconds data logging time
Reporting interval	On-board data storage every second. Output via RJ45 connection
Principle of operation	Laser diode optical detection of actual particulates
International codes range	Up to ISO 22 ( +/- 1 ISO code ) NAS 0 - 12
Calibration	Calibration by recognised on-line methods confirmed by the relevant ISO procedures. MTD - via a certified primary ISO 11171 automatic particle detector using ISO 11943 principles. Particle distribution reporting to ISO 4406:1999
Recalibration and Servicing	Recommended every 12 months
Working pressure	2.5 - 350 bar ( 35 - 5000 psi ). Pressures above 2.5 bar require the use of a Parker Pressure Reducing Valve (PRV) - ACC6NN027
Working viscosity	1 - 300 cSt
Flow range through IOS	40 - 140 ml/minute; controlled at 60 ml/min by IOS's internal pump
Fluid connection interface	INLET: 6 mm push-fit. DRAIN: 4mm push-fit
Ambient storage temp. for unit	-40°C to +80°C; -40°F to +176°F
Operating temperature for unit	-30°C to +80°C; -22°F to +176°F
Operating humidity range	5% RH to 100% RH
Fluid operating temp. (oil)	+5°C to +80°C; +41°F to +176°F
Fluid operating temp. (fuel)	-20°C to +70°C; -4°F to +158°F
Moisture sensor	Linear scale within the range 5% RH to 100% RH
Computer compatibility	IP68-rated RJ45 connection that may be connected to a laptop computer's RJ45 LAN port using the 2 m cable supplied
Power requirement	Regulated power supply supplied with the unit
Certification	IP54 rating ( unit open )
	IP67 rating ( unit closed )
	EC Declaration of Conformity
	Machinery Directive
	EMC EN61000-6-3:2001
	EMC EN61000-6-2:2001
	EMC EN61010-1:2001
	CE Certified
Ordering Information
IOS1220UK	IOS, Mineral MTD online UK
IOS1210UK	IOS, Mineral MTD Offline UK
IOS1221UK	IOS Mineral Wireless online UK
