PCA 3 Gas Analyzers Bacharach

Measurements

  O₂

0 to 20.9%

  CO ( low-range, H₂-compensated )

0 to 4000 ppm

  CO ( high-range, optional )

4001 to 20,000 ppm

  NO ( optional )

0 to 3000 ppm

  NO₂ ( optional )

0 to 500 ppm

  SO₂ ( optional )

0 to 5000 ppm

  Stack temperature

-4 to 2192 °F (-20 to 1200 °C)

  Primary/ambient air temperature

-4 to 999 °F (-20 to 537 °C)

Draft/differential pressure

± 72 inH2O ( ± 179 mbar )

Display

3.5 in. color LCD w/backlight

Power

4x AA batteries or optional wall adapter

Run Time

10 hours minimum (alkaline batteries)

Size ( H x W x D )

9.0 x 3.0 x 2.5 in. ( 22.9 x 7.6 x 6.3 cm )

Weight

2.4 lb. ( 1.1 kg ) including batteries and probe

Fuels[1]

Natural gas, coal, oil 2/4/6, wood, kerosene, bagasse, propane, butane, LPG, digester gas, KOKS, LEG, biofuel, +2 optional custom fuels

Operating Conditions

Analyzer : 32 to 104 °F ( 0 to 40 °C ), 15 to 90% RH ( non-condensing ), 1 ATM ± 10%

Probe tip[2] : 1000 °F ( 538 °C ) maximum, 10 inH2O ( 25 mbar ) maximum draft

Warm-up Time

60 seconds

Memory

1000 locations ( 500/ea for manually-saved and automatic/data-logged records )

Communications

USB 2.0 ( mini-B ), IrDA

Approvals

CE mark, EN 50379-2

Order Information

N. Amer. P/N

Siegert ( Euro.) P/N

Description

0024-8440

0024-8460

PCA®3 225 with O₂ and CO low-range

0024-8441

0024-8461

PCA®3 235 with O₂, CO low-range and NO

0024-8442

0024-8462

PCA®3 245 with O₂, CO low-range and CO high

0024-8443

0024-8463

PCA®3 255 with O₂, CO low-range and SO₂

0024-8444

0024-8464

PCA®3 265 with O₂, CO low-range, NO and NO₂

0024-8445

0024-8465

PCA®3 275 with O₂, CO low-range, NO and SO₂

0024-8446

0024-8466

PCA®3 285 with O₂, CO low-range, CO high-range and NO

0024-8447

0024-8467

PCA®3 225 with O₂, CO low-range and reporting kit

0024-8448

0024-8468

PCA®3 235 with O₂, CO low-range, NO and reporting kit

0024-8449

0024-8469

PCA®3 245 with O₂, CO low-range, CO high and reporting kit

0024-8450

0024-8470

PCA®3 255 with O₂, CO low-range, SO₂ and reporting kit

0024-8451

0024-8471

PCA®3 265 with O₂, CO low-range, NO, NO₂ and reporting kit

0024-8452

0024-8472

PCA®3 275 with O₂, CO low-range, NO, SO₂ and reporting kit

0024-8453

0024-8473

PCA®3 285 with O₂, CO low-range, CO high-range, NO and reporting kit

0024-8454

0024-8475

PCA®3 295 with O₂, CO low-range, NO₂ and SO₂ ( 0024-8475 does not include cary case)

0024-8455

0024-8476

PCA®3 295 with O₂, CO low-range, NO₂, SO₂ and reporting kit
