Petroleum Density Tester SYD-1884 |
|||
|
This instrument is designed and made as per standards GB/T 1884-2000 Crude petroleum and liquid petroleum products - Laboratory determination of density - Hydrometer method & ASTM D1298 Standard Test Method for Density, Relative Density ( Specific Gravity ),or API Gravity of Crude Petroleum and Liquid Petroleum Products by Hydrometer Method. It is used to determine the density of crude petroleum and liquid petroleum. |
|||
|
Features |
|||
|
This instrument is a kind of all-in-one machine. The control box adopts humanized design. The control switch adopts light-touch mode. It's structure is simple and compact. Easy to operate |
|||
|
It adopts intelligent LCD temp. controller. The control rate is fast and overstrike is small. The temp. control can reach ±0.2 ºC |
|||
|
It equips a hard glass vessel and electric stirrer. The temperature in vessel is uniform. Easy to observe the sample |
|||
|
Technical Specifications |
|||
|
Power supply |
AC ( 220 ±10 % ) V,50 Hz |
||
|
Dimension of constant temp. bath |
ะค300 mm × 340 mm |
||
|
Capacity of cylinder |
500 ml |
||
|
Heating power |
700 W,1000 W |
||
|
Temperature controller |
|||
|
(1) Range |
Ambient to 100 ºC |
||
|
(2) Accuracy |
±0.2 ºC |
||
|
(3) Sensor |
Pt 100 |
||
|
Thermometer |
Mercury-in-glass thermometer. Scale division is 0.2 ºC |
||
|
Dimension |
560 × 380 × 580 mm |
||
|
Accessories & documents List |
|||
|
Name |
Unit |
Qty |
Memo |
|
SYD-1884 Petroleum Products Density Tester |
Set |
1 |
|
|
Thermometer ( -20 ~ 102 ºC,scale division 0.2 ºC ) |
Piece |
1 |
|
|
SY-05 Petroleum density meter ( 10 pieces/group ) |
Set |
1 |
|
|
Sensor |
Piece |
1 |
|
|
Thermometer stopper ( 3# ) |
Piece |
2 |
|
|
500ml test tube |
Piece |
2 |
|
|
Stopping ring for thermometer ( 1# ) |
Piece |
4 |
|
|
Rubber stopper ( 21# ) |
Piece |
1 |
|
|
Fuse 10 A ( Φ5 × 20 ) |
Piece |
2 |
|
|
Sample tube holder |
Piece |
2 |
|
|
Operation Manual |
Piece |
1 |
|
|
Temperature controller usage manual |
Piece |
1 |
|
|
Quality Certificate |
Piece |
1 |
|
|
Repair Guarantee |
Piece |
1 |
|
