Radioactive Isotope Identification SAM 940 BNC

Features

Applications

SAM 940 Videos

Emergency Response

Industry Leading Spectral Resolution

Law Enforcement

No Warm Up or Waiting Period

Homeland Security

One Hand / One Glove Operation

Undercover Surveillance

Network Ready with ANSI N42.42 Data Transmission

HAZMAT

Search and Confirm with One Instrument

Industrial

COTS Batteries for Rapid Deployment

Medical

Highest Sensitivity and Response in Real Time

Radiation Safety

Operates Accurately in High Background

Passenger and Freight Monitoring

Auto Calibration and Stabilization with NORM

Non-proliferation Enforcement

Cambio or Peak Easy Compatible

Health Physics

Ships with ANSI-Viewer Software

Food, Water & Public Health Monitoring

DOE Reachback Ready, JAC Ready

Environmental Waste Monitoring

Unattended/Remote Monitoring

Specifications

Detector

Nal Lil, or optional CeBr

Integrated Electronics

Digital signal-processing MCA

Energy Range

18 keV - 3 meV

Controller I/O

10/100 Ethernet port and CompactFlash reader with USB adaptor

Power

8 standard AA batteries

Weight

4.5 lbs with 2" x 2" Nal detector and batteries

Dimensions

12"L x 4"H x 5"W ( excluding detector )

Water/Dust Resistance

IP56

Temperature Range

-20 to 50 °C

Controls

7-key custom keypad with one-thumb operation

Alarm

Visual (On screen) and Audio ( internal speaker or optional headphones )

Detachable Detectors

2"x2" or 3"x3" Nal Detector options, with or without Neutron detector

Integral HV bias supply and optional CeBr detector

Patented Technology

Quadratic Compression Conversion ( QCC ) allows for identification of mixed isotopes in one second

Hysteresis

Provides 97 % ID confidence level in 2 seconds

Optional Modules

Serial GPS receiver for specrtal report mapping, wireless communication

ADC :

Type: base Converter 14-bit pipelined-flash

Conv. Modes: Linear 256, 512, 1024

QCC 256, 512 ( U.S. Patent 5,608,222 )

Calibration

Automatic Stabilization with temperature

Customization

Modifications of isotopes and their associated energy lines, either in the field or using Microsoft Excel

Essentially no limit to number of isotopes or lines

Sound and language preference can be changes

Library

Standard N42.34 ANSI isotopes, ITRAP, IAEA list, medical, industrial, SNM, or user-defined lists

Functions

Nuclide identification, spectrum analysis, dose rate calculation (rem/Sv), total dose, audible search tool, data logging

Options

SAM 940 Systems

Product Descriptions

Model 940-C

SAM 940 w/o detector/CF Card/Acces.

Model 940-2-G

SAM 940 w/ ext. 2.0"x2.0" det., Eagle OS, Quantum NaI, ANSIview

Model 940-2-GN

SAM 940 w/ Neutron, ext. 2.0"x2.0", Eagle OS

Model 940-2-GH

SAM 940 w/ 3He Neutron, ext. 2.0"x2.0", Eagle OS

Model 940-3-G

SAM 940 w/ ext. 3.0"x3.0" det., Eagle OS

Model 940-3-GN

SAM 940 w/ Neutron, ext. 3.0"x3.0", Eagle OS

Model 940-3-GH

SAM 940 w/ 3He Neutron, ext. 3.0"x3.0", Eagle OS

Model 940-2GN-1

SAM 940 with Custom GUI, Gamma/Neutron Detector, Eagle OS

Model 940-2C

SAM 940 w/ CeBr Detector, 1.5"x1.5", Eaglo OS

Model 970 Custom

2" x 2" NaI Stationary SAM Monitor, Portal or Wall Mount, with Reachback, 1 Second Relay, Identification, GUI - Call for quote and design specs
