Specification
| Model | SH-CH-54R | SH-CH-149R | SH-CH-250R | SH-CH-480R |
| Air Circulation | Forced | Forced Convection Type | Forced | |
| Temp Range | -5 C136°C to 60 °C (+23 °F to 60 °F ) | |||
| Temp Control | Microprocess P I D Controller | |||
| Time Range | 00.00 to 99 HR 59 MIN ( MIN SEC ) Selectable Digital Counter Timer | |||
| Temp Accuracy & Stability | ±0.1 ℃ | |||
| Temp Uniformity | ±0.5 ℃ | |||
| Capacity | 54 L | 150 L | 250 L | 480 L |
| Demension Internal,mm | 380 × 340 × 420 | 555 × 450 × 600 | 700 × 450 × 800 | 800 × 600 × 1000 |
| ( W x D x H ) inch | 14.96 x 13.39 x 16.54 | 21.85 x 17.72 x 23.62 | 27.56 x 17.72 x 31.50 | 31.50 x 23.62 x 39.37 |
| Demension External,mm | 540 x 650 x 1170 | 715 x 760 x 1350 | 860 x 760 x 1590 | 960 x 960 x 1935 |
| ( W x D x H ) inch | 21.26 x 25.59 x 46.06 | 28.15 x 29.92 x 53.14 | 33.86 x 29.92 x 62.59 | 37.80 x 37.80 x 76.18 |
| Net Weight | 82 Kg | 117.2 Kg | 156 Kg | 195 Kg |
| Material Internal | Stainless Steel | |||
| Material External | Steel Plate with Powder Heating Coated | |||
| Shelves | 2 Supplied ( 12 Max ) | 2 Supplied ( 17 Max ) | 2 Supplied ( 24 Max ) | 2 Supplied ( 31 Max ) |
| Heater | 800 W | 1000 W | 1200 W | 1800 W |
| Electrical 230 V,50/60 Hz, 1Φ | 3.6 A | 4.6 A | 5.6 A | 8.3 A |
