Revco CxF Series -86°C Ultra-Low Temperature Chest Freezers Thermolyne

Order Information

       * ULT1790-10-D

       * ULT1390-10-V

       * ULT1790-10-V

       * ULT2090-10-D

       * ULT2090-10-V

Features

Eye-level, easy-to-use microprocessor control panel

Message center: 12-character alphanumeric LED displays setpoints, system status and alarm messages

Access code to ensure setpoint security

Optional built-in chart recorder or data logger for continuous monitoring

Easy-to-remove air filter

Construction

Heavy gauge, cold-rolled steel exterior construction with a powder coat paint finish that resists chipping and rust

Stainless steel interior

5″ ( 127 mm ) foamed-in-place, polyurethane insulation

Ergonomic, lockable door handle

Benefits

Convenient interior covers minimize sample exposure to outside conditions.

Inner sub-lids protect bulk samples from ambient exposure during single sample retrievals.

Optional CO₂ or LN₂ safety back-up system included for additional protection in the event of a power or mechanical failure.

Unit includes RS-232 and 4-20 milliamp analog outputs for independent monitoring devices and recorders.

Freezer includes heavy-duty casters with locking tandem wheel design for smooth mobility.

Specification

Backup Systems

Optional CO2 or LN2

Access Security

key lock

Chart Recorder

Optional 7-day chart recorder

Certifications/Compliance

cULus, CE listed

Data Outputs

RS-485, 4-20 mA, dry contacts - standard

Control

Push Button LED

Description

Capacity: 3 cu. ft. ( 84.9 L); 230 V/50 Hz; 5.4A

Amperage

5.4 A

Capacity

3 cu. ft., 84.9 L

Capacity ( English )

3 cu. ft.

Capacity ( Metric )

84.9 L

Dimensions ( L x W x H ) Exterior

29.9 x 28.5 x 43.8 in. ( 75.9 x 72.4 x 111.3 cm )

Dimensions ( D x W x H ) Interior

18.5 x 18.5 x 16.5 in. ( 47 x 47 x 41.9 cm )

Hertz

50 Hz

Holds

63 boxes

Insulation

Polyurethane Foam

Model

Revco

Plug Type

European

Shipping Weight ( English )

432 lb.

Shipping Weight ( Metric )

196 kg

Temperature Range

-50° to -86°C

Voltage

230 V

Electrical Requirements

230 V 50 Hz

Interior

Stainless-steel

Operating Modes

Standard Operation

Regulatory Approvals

CE

Smart View Compatibility

SmartView Compatible

Setpoint Security

Single ID

Unit Weight ( Metric )

186 kg

Unit Weight ( English )

392 lb.

Voltage Compensation

Buck/Boost
