Rotary Evaporator WEV-1001V & WEV-1001L Daihan Scientific

Specification

Model

“WEV-1001V”

“WEV-1001L”

Condenser Type

Vertical-type

Diagonal-type

Flask Capacity

Evaporating

Included 2 × Evaporating Flasks : 1 × 0.5 Lit. & 1 x 1Lit.,

Available 100 ~ 2,000 ㎖ Evaporating Flask ( Optional )

Receiving

Included 1 ea 1 Lit. Flask

Rotary Speed

10 ~ 180 rpm

Evaporating Capability

20 ml/min

Cooling Surface

1,300 cm2

Achievable Vacuum

399.9 Pa ( below 3 mmHg )

Bath Capacity

7.4 Lit. / Φ260 ×140 mm

Temp. Range

Ambient Temperature +5℃ ~ 99℃

Functional of Lifting Table

Weight Balancing Gliding Elevating & Manual Lifting

Elevating Stroke

100 ~ 250 mm

Vacuum Sealing

Double Sealing Rings made of Teflon+Vinton Materials

Power Consumption

Motor : 25 W, Heater : 1.5 KW

Controller & Display

PID Controller, Digital display

Dimension & Net Weight

560 × 320 × h 660 mm / 9.5 kg

750 × 320 × h 540 mm / 9.5 kg

Power Supply & Cord Plug

220 V, 60 Hz
