Rotary Evaporator WEV-1050 Daihan Scientific

Specification

Model

“WEV-1050”

Rotary Bottle

50 Lit., Flange

Opening Φ125 mm

Collecting Bottle

20 Lit.

Condenser

Standing, Main & Auxiliary Cooling and Highly Efficient

3 Circulating Cold Trap

Temp. Range

0 ℃ ~ 99 ℃

Rotary Speed

10 ~ 110 rpm

Evaporating Capability

Water : 9 Lit./h, Alcohol : 19 Lit./h

Cooling Surface

Main Condensr 9,500 cm²

Auxiliary Condensr 5,000 cm²

Achievable Vacuum

399.9 Pa ( below 3 mmHg )

Functional of Lifting Table

Electric & Manual

Elevating Stroke

0 ~ 230 mm

Vacuum Sealing

PTFE and Fluorine Rubber Dual Rotating Seal

Motor

Phase AD Induction Motor

90 W

Heating Boiler

Stainless steel Water Bath

Display

Digital display

Power Consumption

8.3 KW

Dimension

1320 × 770 × h 2340 mm

Power Supply & Cord Plug

380 V, 50 Hz
