Rotor Desicant Dehumidifier RDH |
|||
|
Model |
Description |
Specifications |
Dimensions |
|
RDH-180P |
Desiccant dehumidifier |
· Dehumidifying capacity : 0.5 kg/h |
* Unit size : |
|
12 L/day ( 20 ℃,60 % ) |
· Dry air flow :180 m³/h; Wet air flow : 60 m³/h |
250 * 224 * 495 mm |
|
|
|
· Applied temperature from -10 ℃ to 45 ℃ |
* Packing size : |
|
|
· Maximum Input Power : 1000 w |
350 * 300 * 550 mm |
||
|
· Heater current : 4 A |
|
||
|
· Supply fuse 220-240V/ 50Hz |
|||
|
· Stainless steel 304 |
|||
|
· Operation indicator, timer switch |
|||
|
· Washable rotor imported from Sweden |
|||
|
· Built-in heat recovery |
|||
|
· Automatic faults detecting system, long lifespan |
|||
|
· Approval : CE/CCC/RoHs |
|||
|
RDH-200P |
Desiccant dehumidifier |
· Dehumidifying capacity : 0.7 kg/h |
* Unit size : |
|
16.8 L/day ( 20 ℃,60 % ) |
· Dry air flow : 210 m³/h; Wet air flow: 80 m³/h |
250 * 224 * 695 mm |
|
|
|
· Applied temperature from -10 ℃ to 45 ℃ |
* Packing size : |
|
|
· Maximum Input Power : 1300 w |
380 * 350 * 850 mm |
||
|
· Heater current : 4.5 A |
|
||
|
· Supply fuse 220-240 V/50 Hz |
|||
|
· Stainless steel 304 |
|||
|
· Operation indicator, timer switch |
|||
|
· Washable rotor imported from Sweden |
|||
|
· Built-in heat recovery |
|||
|
· Automatic faults detecting system, Long lifespan |
|||
|
· Approval : CE/CCC/RoHs |
|||
|
RDH-550P |
Desiccant dehumidifier |
· Dehumidifying capacity : 3 kg/h |
* Unit size : |
|
72 L/day ( 20 ℃,60 % ) |
· Dry air flow : 500 m³/h; Wet air flow : 160 m³/h |
540 * 470 * 450 mm |
|
|
|
· Applied temperature from 0 ℃ to 45 ℃ |
* Packing size : |
|
|
· Maximum Input Power: 6000 w |
560 * 480 * 510 mm |
||
|
· Heater current : 10 A |
|
||
|
· Supply fuse 220-240 V/50 Hz |
|||
|
· Stainless steel |
|||
|
· Operation indicator,timer switch |
|||
|
· Washable rotor imported from Sweden |
|||
|
· Built-in heat recovery |
|||
|
· Automatic faults detecting system, Long lifespan |
|||
|
· Approval : CE/CCC/RoHs |
|||
|
RDH-1500P |
Desiccant dehumidifier |
· Dehumidifying capacity : 10 kg/h |
|
|
240 L/day ( 20 ℃,60 % ) |
· Dry air flow : 1500 m³/h ; Wet air flow : 580 m³/h |
||
|
|
· Applied temperature from 0 ℃ to 45 ℃ |
||
|
· Maximum Input Power : 14.7 KW |
|||
|
· Heater current : 50/25 A |
|||
|
· Supply fuse 3 * 230/400 V50 Hz |
|||
|
· Stainless steel 304 |
|||
|
· Operation indicator,timer switch |
|||
|
· Washable rotor imported from Sweden |
|||
|
· Built-in heat recovery |
|||
|
· Automatic faults detecting system, Long lifespan |
|||
|
· Approval : CE/CCC/RoHs |
|||
|
|
|
|
|
