Sample Concentrator, SBHCONC/1 Stuart

Fast efficient sample concentration

Suitable for all tube configurations

Compatible with Stuart three block heaters only

A sample concentrator is a fast and convenient way of concentrating multiple samples in a block heater at once. Utilising a simple gas delivery system the sample concentrator passes gas over the surface of your samples via stainless steel needles. This in combination with the heat from the block heater below produces ideal conditions for fast, efficient evaporation.

The gas delivery needles are inserted into a silicon membrane, in virtually any configuration. The height of the sample concentrators gas reservoir is located on an adjustable stand for accurate height control. This combines to make the sample concentrator compatible with any combination of block heater sample vessels.

The gas delivery needles are available in either 76 mm or 127 mm lengths to suit various tube heights, optional PTFE coating is available for corrosive solutions.

The Stuart sample concentrator is only compatible with the SBH130D/3 and SBH200D/3.

Order Information

Model

Description

SBHCONC/1

Sample Concentrator

F7209

Needles, 76 mm ( pack of 100 )

F7210

Needles, 127 mm ( pack of 100 )

FSC4NCS

Needles, 76 mm, PTFE coated ( pack of 100 )

FSC4NCL

Needles, 127 mm, PTFE coated ( pack of 100 )
