See-saw rockers - SSM4 & SSL4 Stuart

Small space saving design or laboratory sized units available

Digital speed control and built-in timer

Optional tier system available to increase capacity

Both models have a see-saw rocking action that creates a wave motion within vessels such as culture flasks, Petri dishes etc. Digital selection of both speed and time facilitates accurate and reproducible conditions. Both parameters are controlled via an easy to use encoder control knob and displayed on the bright LED display.

Both models are supplied with a non-slip mat which holds flat based vessels securely in place during mixing. An accessory tier system can be fitted in seconds, without the need for tools, tripling the available space for samples. Each tier is securely held in place by magnets.

Model

SSM4

SSL4

Rocking action

See-saw wave

See-saw wave

Platform dimensions ( w x l )

235 x 235 mm

355 x 355 mm

Speed range

5 to 70 rpm

5 to 70 rpm

Angle of tilt

7°

7°

Maximum load

3 kg

10 kg

Overall dimensions ( w x d x h )

240 x 300 x 150

360 x 420 x 160

Tier height, mm

125/tier

125/tier

Operational temp. range

+4 to +40°C

+4 to +40°C

Max. permissible humidity

80%

80%

Net weight

5 kg

10 kg

Electrical supply

230 V, 50 Hz, 50 W

230 V, 50 Hz, 50 W

Model

Description

SSM4

Rocker, see-saw, mini

SSM3/1

Tier system ( 2 platforms plus 8 bars ) fits SSM4

SSL4

Rocker, see-saw, lab scale

SSL3/1

Tier system ( 2 platforms plus 8 bars ) fits SSL4
