Vibratory Sieve Shaker AS 200 Digit cA Retsch

The analytical sieve shakers of the series AS 200 are used in research & development, quality control of raw materials, interim and finished products as well as in production monitoring.

The controllable electromagnetic drive offers an optimal adaption for every product. Sharp fractions are obtained even after short sieving times.

The AS 200 digit cA sieve shaker is recommended whenever controlled amplitude, digital display of vibration height and time and interval operation are required.

Application Examples

Cement clinker, chemicals, coffee, construction materials, fertilizers, fillers, flours, grains,metals powders, minerals, nuts, plastics, sand, seeds, soils, washing powder, ...

Product Advantages

NEW : controlled amplitude

Suitable for dry and wet sieving

Excellent separation efficiency even with short sieving times

Efficient electromagnetic drive

3-D throwing motion which ensures optimum use of the open sieve area and lets the sample move equally over the whole sieving surface

Maintenance-free

Sieve stack up to 510 mm height

Free adjustment of all process parameters ( time, amplitude )

Interval operation ( fix 10 s )

Digital display of vibration height and time

Easy operation, ergonomic design

Features

Applications

Separation, fractioning, particle size determination

Field of application

Agriculture, biology, chemistry / plastics, construction materials,engineering / electronics, environment / recycling, food, geology /metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material

Powders, bulk materials, suspensions

Measuring range*

20 µm - 25 mm

Sieving motion

Throwing motion with angular momentum

Max. batch/feed capacity

3 kg

Max. number of fractions

9 - 17

Max. mass of sieve stack

4 kg

Amplitude

Digital, 0.2 - 3.0 mm

Controlled amplitude

Yes

Time display

Digital, 1 - 99 min

Interval operation

10 s

Storable SOPs

1

Suitable for dry sieving

Yes

Suitable for wet sieving

Yes

USB interface

-

Including test certificate/can be calibrated

-

Suitable sieve diameters

100 mm / 150 mm / 200 mm / 203 mm ( 8" )

Max. height of sieve stack

510 mm

Clamping devices

"Standard", "comfort", each for wet and dry sieving

Protection code

IP 54 / IP 20

Electrical supply data

Different voltages

Power connection

1 phase

W x H x D

417 x 212 x 384 mm

Net weight

~ 35 kg

Standards

CE
