Vibratory Sieve Shaker AS 450 Basic Retsch

The AS 450 basic, is a budget-priced alternative to the AS 450 control sieve shaker. The new sieve shaker covers a size range from 25 μm to 125 mm and accepts loads of up to 15 kg. Time and amplitude are digitally set, a memory function allows storage of one program. The AS 450 basic is suitable for dry and wet sieving. It is the economic solution for customers who need to sieve larger quantities of dry material with reliable results.

Application Examples

Cement clinker, chemicals, coal, coke, construction materials, fillers, minerals, ores, plastics,sand, soils, ...

Product Advantages

Suitable for dry and wet sieving

Excellent separation efficiency even with short sieving times

Efficient electromagnetic drive

3-D throwing motion which ensures optimum use of the open sieve area and lets the sample move equally over the whole sieving surface

Up to 12 fractions in one sieving operation

Free digital adjustment of all process parameters ( time, amplitude, interval )

Mobile operation panel for comfortable, intuitive handling

Maintenance-free

Easy operation, ergonomic design

Robust steel housing

Features

Applications

Separation, fractioning, particle size determination

Field of application

Chemistry /plastics, construction materials,engineering/ electronics,environment / recycling, geology / metallurgy, glass / ceramics

Feed material

Powders, bulk materials

Measuring range*

25 µm - 125 mm

Sieving motion

Throwing motion with angular momentum - 3D movement

Max. batch/feed capacity

15 kg

Max. number of fractions

12 / 8*

Max. mass of sieve stack

50 kg

Amplitude

Digital, 0 - > 2 mm

Time display

Digital, 0 - 99 min

Interval operation

Yes

Storable SOPs

1

Suitable for dry sieving

Yes

Suitable for wet sieving

Yes

Serial interface

-

Suitable sieve diameters

400 mm / 450 mm

Max. height of sieve stack

830 mm

Clamping devices

"standard" ( two models, one for dry, one for wet sieving )

Electrical supply data

Different voltages

Power connection

1-phase

W x H x D

680 x 280 x 680 mm

Net weight

~ 140 kg

Standards

CE
