Sieve Shaker OCTAGON 200CL Endecotts

Advantages

'Closed Loop' total amplitude control ensures reproducible sieving

Digital controls for easy and reliable operation

Easy-to-use sieve clamping system

Accepts up to 8 full height 200 mm ( 8" ) diameter sieves

Suitable for dry and wet sieving

3D sieving motion allows for high separation efficiency and non blinding sieving action

Full compatibility with new SieveWare evaluation & control software via RS232 Port ( printed or digital protocols )

Voltage-independent

No mechanical moving parts

Compact & portable

Specifications

Range

20 µm to 125 mm

Drive / sieving motion

Electromagnetic 3D

Max. batch / feed capacity

3 kg

Max. number of sieves

8 full height / 16 half height ( 200 mm sieves )

Amplitude

0 - 3 mm

Digital setting in 0.1 mm steps

"Closed Loop" amplitude control

Speed

3,000 min-1 at 50 Hz

Time display

Digital, 00:10 - 99:50 min

Interval operation

Yes ( two modes )

Suitable for dry sieving

Yes

Suitable for wet sieving

Yes

Serial interface

Yes ( RS232 )

Sieve diameter

100 / 200 mm

8''

Max. height of sieve stack

Up to 450 mm

Clamping device

Quick-release clamping system ( included )

Model

Benchtop

Protection code

IP 54

Electrical supply

100-240V 50/60Hz

Power connection

1 - Phase

W x H x D

418 x 232 x 435 mm

Net weight

~35 kg

Standards

CE
