Digital Ultra-Low Temp. Freezer SimpleFreez U300, U400, U500, U700 Daihan Scientific

Specification

Model

SimpleFreez

SimpleFreez

SimpleFreez

SimpleFreez

U300

U400

U500

U700

Capacity

308 Lit.

393 Lit.

503 Lit.

714 Lit.

Freezing System

SimpleFreezTM  System

-86 ℃~-65 ℃

-80 ℃~-65 ℃

Temp.

Range

at Room Temperature of 30℃ and Humidity of 70 %

Sensor

PT100 Sensor

Compressor

Hermetic Type

Condenser Type

Block Condenser, No Pin, Filter Free Mechanism

Refrigerant

Natural ( CFC Free Refrigerant System )

Controller & Display

7″Full Touch Screen TFT LCD ( Smart-LabTM Controller )

Shelves

Included 3 Stainless steel Shelves

Max. Q'ty of Racks

12 pcs of 15 ( 3 × 5 )-

16 pcs of 15 ( 3 × 5 )-

16 pcs of 20 ( 4 × 5 )-

24 pcs of 20 ( 4 × 5 )-

Placed Rack

Placed Rack

Placed Rack

Placed Rack

( RFU3040 )

( RFU3040 )

( RFU50 )

( RFU50 )

Material

Internal

Stainless steel ( #304 )

External

Powder Coated steel Plate

Inner Door

Powder Coated Stainless steel ( #304 )

Others

CE & RoHS Certified, PL ( Product Liability ) Insurance, GD-mark

Touch-Screen TFT LCD Smart-LabTM  Controller

CFC-Free Refrigerants

Built in Standard Warning and Alarm Functions

RS232 Communication link, Remote Control Software

Chamber Dimension

( W x D x H )

Internal ( mm )

470 × 500 × 1,310

600 × 500 × 1,310

600 × 640 × 1,310

880 × 620 × 1,310

External ( mm )

710 × 750 × 1,900

840 × 750 × 1,900

840 × 890 × 1,900

1,120 × 870 × 1,900

Net Weight

180 kg

210 kg

240 kg

320 kg

Packing Size ( W x D x H ) ( cm )

110 × 110 × 222

116 × 116 × 222

116 × 124 × 222

140 × 140 × 221

& Gross Weight

275 kg

296 kg

327 kg

442 kg

Power Consumption

352 Wh

373 Wh

458 Wh

503 Wh

Power Supply & Cord Plug

1 Phase, AC 120V, 60Hz or  AC 230V, 50 / 60Hz
