DuoFreezTM SMART Digital Ultra-Low Temp. Freezer Daihan Scientific

Specification

Model

DuoFreez U300

DuoFreez U400

DuoFreez U500

DuoFreez U700

Capacity

308 Lit.

393 Lit.

503 Lit.

714 Lit.

Freezing System

DuoFreezTM  System

Temp.

Range

-95℃~-65℃

-90℃~-65℃

at Room Temp. of 30℃ and Humidity of 70%

Sensor

PT100 Sensor

Compressor

Hermetic Type

Condenser Type

Block Condenser, No Pin, Filter Free Mechanism

Refrigerant

Natural ( CFC Free Refrigerant System )

Controller & Display

7″Full Touch Screen TFT LCD ( Smart-LabTM  Controller )

Shelves

Included 3 Stainless steel Shelves

Max. Q'ty of Racks

12 pcs of 15 ( 3 × 5 )-

16 pcs of 15 ( 3 × 5 )-

16 pcs of 20 ( 4 × 5 )-

24 pcs of 20 ( 4 × 5 )-

Placed Rack

Placed Rack

Placed Rack

Placed Rack

( RFU3040 )

( RFU3040 )

( RFU50 )

( RFU50 )

Material

Internal

Stainless steel ( #304 )

External

Powder Coated steel Plate

Inner Door

Powder Coated Stainless steel ( #304 )

Others

KGMP Certified, CE & RoHS Certified, GD-mark PL ( Product Liability ) Insurance, CFC-Free Refrigerants Touch-Screen TFT LCD Smart-LabTM  Controller

Built in Standard Warning and Alarm Functions

RS232 Communication link, Remote Control Software

Chamber Dimension

( W x D x H )

Internal ( mm )

470 × 500 × 1,310

600 × 500 × 1,310

600 × 640 × 1,310

880 × 620 × 1,310

External ( mm )

710 × 750 × 1,900

840 × 750 × 1,900

840 × 890 × 1,900

1,120 × 870 × 1,900

Net Weight

220 kg

260 kg

300 kg

320 kg

Packing Size ( W x D x H ) ( cm )

110 × 110 × 222

116 × 116 × 222

116 × 124 × 222

140 × 140 × 221

& Gross Weight

300 kg

352 kg

352 kg

442 kg

Power Consumption

Dual mode

398 Wh

474 Wh

507 Wh

596 Wh

Eco. mode

352 Wh

373 Wh

458 Wh

503 Wh

Power Supply & Cord Plug

1 Phase, AC 120V, 60Hz or  AC 230V, 50 / 60Hz
