Sonica Ultrasonic Cleaners 2200 S3 Soltec |
|
|
Sonica Ultrasonic Cleaners 2200 M S3 Soltec |
|
|
Sonica Ultrasonic Cleaners 2200 MH S3 Soltec |
|
|
Sonica Ultrasonic Cleaners 2200 ETH S3 Soltec |
|
|
Sonica Ultrasonic Cleaners 2200 EP S3 Soltec |
|
|
Ultrasonic Cleaner 3 Litres |
|
|
Technical Data |
|
|
Main line voltage |
230/240V~50/60 Hz |
|
Main input power/consumption |
130 W |
|
Main input power with heating |
305 W |
|
Peak HF Ultrasound Power |
260 W |
|
US frequency |
40 Khz ± 5 % with SWEEP SYSTEM Technology |
|
Liquid drain |
Mod. ETH-EP ( tube 10 x 8 mm ) |
|
Transducers |
2 ( 2 Piezoelectric ceramics each ) |
|
Tank capacity [ L ] |
3 |
|
Weight [ KG ] |
3,5 |
|
Installation category |
Class II according to EN 61010-1 |
|
Environmental conditions |
Temp. Rel. Hum. 80 % up to 31 °C with linear decrease up to 50 % at 40 °C |
|
IP grade |
IP 22 |
|
CE-compliant |
2004/108/EC EMC Directive ( EN61326 ) |
|
2006/95/EC LV Directive ( EN 61010-1 ) |
|
|
93/42/CEE Medical Device Directive |
|
|
Risk Class I according to the rule 12 to the Directive 93/42/EEC Annex IX |
|
|
Approximately Internal Tank Dimensions |
|
|
W/D/H ( mm ) |
240 / 140 / 100 |
|
Max filling volume tank |
3 L |
|
External Appliance Dimensions |
|
|
W/D/H ( mm ) |
270 / 170 / 260 |
|
Max operative volume |
2,35 L |
