| Specification | |
| baseline Flatness | <0.003 A |
| 325 nm – 1000 nm smoothed | |
| Compartments | Accessible from top, front or side |
| Able to accommodate cells up to 100 mm pathlength | |
| Available accessory for test-tubes up to 25 mm diameter and 150 mm height | |
| Removable, washable sample compartment liner with magnetic placement and hold-down | |
| Connections | USB-A on front face supports flash memory devices for method and data storage |
| USB-B on side supports connection to a Windows™ computer running optional remote control software. | |
| Description | GENESYS 30 Visible Spectrophotometer |
| Detector Type | Silicon Photodiode |
| Dimensions ( L x W x H ) | 35.5 cm x 38.5cm x 19.5 cm |
| Display | 5" diagonal, 32 bit color display, 800 x 480 pixels |
| Drift | <0.002A/Hr |
| At 500nm after 2 hr warmup. Typical <0.004A/hr after 1hr warmup | |
| Electrical Requirements | External AC to DC converter.Voltage and Hz selected automatically, 100-250 volts, 50-60 Hz |
| Keypad | Tactile rubber 23 keys with numeric keypad |
| Lamp | 1000 Hrs typical service life |
| Languages | English, Spanish, German, French, Italian, Portuguese, Russian,Chinese, Japanese, Korean, Thai, Arabic |
| Noise | ≤0.001A at 0 A |
| ≤0.001A at 1 A | |
| ≤0.002A at 2 A | |
| RMS at 500 nm. 60 consecutive measurements | |
| Optical Design | Single beam |
| Photometric Accuracy Instrument | ±0.002 A ( 0 - 0.3A ) |
| 0.5 % of ABS reading ( 0.301 A - 2.5 A ) | |
| Photometric Display | -3A to +3A, 0 to 200 000 %T, 0 to 9 999 999 C |
| Photometric Range | -3A to +3 A |
| Photometric Repeatability | ± 0.002 A |
| Measured at 1.0 A @546 nm | |
| Printer | Thermal printer accessory with 80 mm width paper |
| Spectral Bandwidth | 5 nm |
| Stray Light | <0.1 %T at 340 nm and 400 nm |
| Measured using glass cutoff filters or NaNO2 at 340 nm | |
| Wavelength Accuracy | ± 2 nm |
| Wavelength Data Interval | 1 nm |
| Wavelength Range | 325 nm – 1100 nm |
| Wavelength Repeatability | < ±1 nm |
| Wavelength Scan Speed | Automatic – up to 1200 nm/min |
| Weight ( Metric ) | 7.5 kg |
