Tablet Dissolution Apparatus DS 14000 Auto Labindia Analytical

Labindia Dissolution Tester : DS14000 ( Auto ) is a completely automated system with imported peristaltic pump along with sample collector with in-built facility to study the recovery test & rinse the entire sampling path to reduce cross contamination & carryover effects. The 12+2 ( 6 +1 & 6 +1 ) vessel configuration comes with moulded Water Bath which enables comparative studies.

Standard Features

1. Advanced micro controller based user friendly state-of-the-art product design with alphanumeric splash waterproof polyester soft keys. User interactive software in dialogue mode for ease of operation with protection against invalid entries.

2. Support USP 1, 2, 5 & 6 and is complaint with USP, BP, IP specifications. Apparatus for Intrinsic test & Stationary basket methods are also available

3. Conical shaped low evaporation recovery lids on the tablet dispenser reduces the media loss during long dissolution run

4. Mono shaft design allows easy changeover between Apparatus I & II thus eliminates the routine height validation check per USP

5. Apparatus for Intrinsic test & Stationary basket methods are also available

6. Tablet Dispenser drops 12 dosage form at single instance

7. Non-Volatile Memory storage of 15 methods with parameter

8. GLP Complaint report format with Alphanumeric entries of Sample name & identification number for authentication

9. RS 232C Interface for PC connectivity & Parallel port for printer

Intelligent Sampling System

Intelligent motorized sampling manifold complies to USP requirements

Temperature monitoring system automatically records temperature of 12 vessels at specified time points

Peristaltic Pump

Bi-directional 24 channel peristaltic pump with tygon tubings from ISMATEC, Switzerland

Click-n- go Cassette design along with volume calibration through software

Sample Collection

Microprocessor controlled sample collector positions the sample tray appropriately

12 x 6 x 2 collection trays are available.

Option of 1.5 ml & 2 ml HPLC vials tray is available
