Tap Density Tester ETD-1020 Electrolab

Features

Supports USP 1 ( 300 taps per min ) and USP 2 ( 250 taps per min ) and ASTM test methods

Simultaneous rotating and tapping motion assures as evenly packed surface

Calculation of test results like tapped density, compressibility index and Hausner ratio

Printer port for documenting test results as per GMP/GLP standards

LAN connectivity for data transfer to a computer

Specification

Model

EDT-1020

Test methods

USP I and USP II, ASTM ( optional )

No. of station

2

Tap height

USP I : 14 mm /- 2 mm, USP II : 3 mm /- 0.2 mm

Taps / minute

USP I : 300 mm /- 15, USP II : 250 /- 15

No. of tap counts

10, 500, 1250

No. of taps ( user mode )

1 to 9999

Display

20 x 4 character LCD

Type of drive

Direct drive with stepper motor

Printer interface

Serial port

PC connectivity

Standard : Serial

Optional  : External LAN

Dimensions ( W x H x D )

36 cm x 20 cm x 32 cm

Weight

17 kgs
