Temp. Humidity Chamber ThermoStable STH-E155,STH-E305,STH-E420,STH-E800 Daihan Scientific

Specification

Model

ThermoStable

ThermoStable

ThermoStable

ThermoStable

Specification

STH-E155

STH-E305

STH-E420

STH-E800

Capacity

155 Lit.

305 Lit.

420 Lit.

800 Lit.

Temp.

Range

-20 ℃ ~ +80 ℃

Accuracy

±0.3 ℃ ( Stability ±1.0 ℃ )

Humidity

Range

30% ~ 95% RH

Accuracy

±2 % ( Stability ±3 % RH )

Dimension ( W × D × H )

Interior ( mm )

505 × 505 × 610

620 × 620 × 800

750 × 660 × 850

1000 × 800 × 1000

Exterior ( mm )

745 × 920 × 1645

820 × 1290 × 1720

990 × 1075 × 1885

1200 × 1100 × 1920

Heater

for Temperature

1.5 kW

2.0 kW

2.2 kW

2.5 kW

for Humidity

2.0 kW

3.0 kW

3.0 kW

3.0 kW

Compressor

7/8 HP

1.5 HP

1.5 HP

3 HP

Refrigerant

CFC – Free ( R-404A ) Refrigeration System

Controller & Display

Smart-Lab Controller, 7” Full Touch Screen TFT LCD

Program Function

Multiple Programs ( Patterns by multiple Segments ) Supported

Sensor

PT100 & Capacitive Sensor

Material

Internal

Stainless-steel ( ＃304 )

External

Powder Coated steel

Shelves

3 ea of Perforated Stainless steel Shelves of Adjustable Position

Safety Device

Hi-Low Temp. Protector, Over Current & Leakage Breaker, Water Level Sensor

Others

CE Certified

PL ( Product Liability ) Insurance

Net Weight

290 kg

309 kg

378 kg

558 kg

Packing Dimension ( W × D × H )

99 × 112 × 185

122 × 122 × 205

128 × 128 × 216

149 × 132 × 220

Gross Weight

355 kg

369 kg

478 kg

678 kg

Power Consumption

4.4 kW

5.7 kW

6.3 kW

8.2 kW

Electric Reqts

1 Phase AC 120 V, 60 Hz or AC 230V, 50/60 Hz or 3 Phase
