Thermolyne Industrial Benchtop Muffle Furnaces |
||
|
Model FD1530M, FD1530M-33, FD1540M, FD1540M-33 |
||
|
Specification |
||
|
Product Size |
FD1530M |
FD1530M-33 |
|
Amperage |
9.3 A |
6.5 A |
|
Capacity ( Metric ) |
2.2 L |
|
|
Certifications/Compliance |
All units cUL, UL listed; -33 units also CE marked. |
|
|
Capacity |
0.08 cu.ft., 2.2 L |
|
|
Capacity ( English ) |
0.08 cu.ft. |
|
|
Depth ( English ) Int |
9 in. |
|
|
Depth ( Metric ) Int |
22.8 cm |
|
|
Dim ( D x W x H ) Int |
9 x 4 x 3.75 in. |
|
|
( 22.8 x 10.1 x 9.5 cm ) |
||
|
Dim ( L x W x H ) Ext |
18 x 11 x 16.5 in. |
|
|
( 45.7 x 27.9 x 41.9 cm ) |
||
|
Height ( English ) Ext |
16.5 in. |
|
|
Height ( English ) Int |
3.75 in. |
|
|
Height ( Metric ) Int |
9.5 cm |
|
|
Height ( Metric ) Ext |
41.9 cm |
|
|
Length ( English ) Ext |
18 in. |
|
|
Hertz |
50/60Hz |
|
|
Length ( Metric ) Ext |
45.7 cm |
|
|
Power Consumption |
2230 w |
|
|
Shipping Weight ( English ) |
52 lb. |
|
|
Shipping Weight ( Metric ) |
23.5 kg |
|
|
Temp Control |
Digital single setpoint |
|
|
Temp Range ( Metric ) |
100° to 1200°C |
|
|
Type |
Single setpoint |
|
|
Voltage |
240 V |
|
|
Width ( English ) Int |
4 in. |
|
|
Width ( English ) Ext |
11 |
|
|
Width ( Metric ) Ext |
27.9 |
|
|
Electrical |
240 V 50/60 Hz |
|
|
Width ( Metric ) Int |
10.1 cm |
|
|
|
||
|
Product Size |
FD1540M |
FD1540M-33 |
|
Amperage |
9.3 A |
6.5 A |
|
Capacity ( Metric ) |
2.2 L |
|
|
Certifications/Compliance |
All units cUL, UL listed; -33 units also CE marked. |
|
|
Capacity |
0.08 cu.ft., 2.2 L |
|
|
Capacity ( English ) |
0.08 cu.ft. |
|
|
Depth ( English ) Int |
9 in. |
|
|
Depth ( Metric ) Int |
22.8 cm |
|
|
Dim ( D x W x H ) Int |
9 x 4 x 3.75 in. |
|
|
( 22.8 x 10.1 x 9.5 cm ) |
||
|
Dim ( L x W x H ) Ext |
18 x 11 x 16.5 in. |
|
|
( 45.7 x 27.9 x 41.9 cm ) |
||
|
Height ( English ) Ext |
16.5 in. |
|
|
Height ( English ) Int |
3.75 in. |
|
|
Height ( Metric ) Int |
9.5 cm |
|
|
Height ( Metric ) Ext |
41.9 cm |
|
|
Length ( English ) Ext |
18 in. |
|
|
Hertz |
50/60 Hz |
|
|
Length ( Metric ) Ext |
45.7 cm |
|
|
Power Consumption |
2230 w |
|
|
Shipping Weight ( English ) |
52 lb. |
|
|
Shipping Weight ( Metric ) |
23.5 kg |
|
|
Temp Control |
Digital programmable 1 program/8 segments |
|
|
Temp Range ( Metric ) |
100° to 1200°C |
|
|
Type |
Multisegment |
|
|
Single program |
||
|
Voltage |
240 V |
|
|
Width ( English ) Int |
4 in. |
|
|
Width ( English ) Ext |
11 |
|
|
Width ( Metric ) Ext |
27.9 |
|
|
Electrical |
240 V 50/60 Hz |
|
|
Width ( Metric ) Int |
10.1 cm |
|
